| Product Type | Security appliance |
| Product Name | SonicWall NSA 4650 TotalSecure Advanced Edition |
| Manufacturer Part Number | 01-SSC-4094 |
| UPC | 758479040941 |
| Form Factor | Rack-mountable - 1U |
| Dimensions (W x D x H) | 16.9 in x 16.3 in x 1.8 in |
| Weight | 15.21 lbs |
| Shipping Weight | 24.91 lbs |
| Flash Memory | 32 GB |
| Power Requirements | AC 120/230 V (50/60 Hz) |
| Power Consumption | 93.6 Watt |
| Power Provided | 350 Watt |
| Power Supply | Internal |
| Power Redundancy | Optional |
| Installed Power Supply Units | 1 |
| Max Supported Power Supply Units | 2 |
| MTBF | 17.6 years |
SONICWALL NSA 4650 TotalSecure Adv Edition, 1YR, Rackmount, 6Gbps Firewall
Photo is for illustration purposes only. Actual product may be different.
Regular price
$13,554.00
Regular price
Sale price
$13,554.00
Unit price
per
MSRP: $15,346.00
Shipping calculated at checkout.
Couldn't load pickup availability
- Firewall throughput up to 6 Gbps and DPI throughput of 1.2 Gbps
- Supports up to 3 million SPI and 1 million DPI concurrent connections
- Includes 1-year TotalSecure unified threat management subscription
- Expansive connectivity: 2x 10Gb SFP+, 4x 2.5Gb SFP, 4x 2.5Gb RJ-45, 16x 1Gb RJ-45
- Advanced routing and remote management protocols: OSPF, BGP, SNMP, HTTPS
- Rack-mountable 1U form factor with optional redundant power support
Shipping & Returns
Shipping & Returns
All our products can be shipped anywhere in the Continental United States.
Key Benefits
Eye-Insights™ by Eye-In Technologies
AI-Powered Summaries from Online Customer Reviews
AI-Powered Summaries from Online Customer Reviews
Eye-Insights™ are generated by proprietary AI that analyzes real online customer reviews to highlight top pros and key product features. While we aim for accuracy, insights are provided “as-is” and individual results may vary.
- Delivers high-performance protection with 6 Gbps firewall and 3 Gbps VPN throughput, suited for growing networks with heavy traffic demands
- Comes fully equipped with a 1-year TotalSecure license, bundling multiple security features into a single deployable unit for simplified management
- Built to last with 17.6 years MTBF and TAA compliance, ensuring long-term reliability and governmental procurement eligibility
Product Overview
The SONICWALL NSA 4650 TotalSecure Advanced Edition is a rack-mounted, high-performance network security appliance designed for mid-sized enterprises. Featuring 6 Gbps firewall throughput, 3 Gbps VPN capabilities, and 1.25 Gbps anti-malware performance, it provides fast and secure data transmission. The included 1-year TotalSecure license delivers comprehensive protection through intrusion prevention, DPI, anti-malware, and web filtering.
Supporting up to 3 million SPI connections and 128 access points, it is built for scalability. The appliance offers a rich I/O configuration with 2 x 10Gb SFP+, 4 x 2.5Gb SFP and RJ-45, and 16 x 1Gb Ethernet ports, allowing flexible deployment. Optional power redundancy, enterprise VoIP protocol support, and a robust routing suite ensure operational continuity and adaptability.
Compliant with TAA and equipped with a 17.6-year MTBF, the NSA 4650 brings reliability and advanced threat coverage together, making it a smart investment for growing networks.
Specifications
Product Overview
Wireless Features
| Maximum Number of Supported Access Points | 128 |
Compliance & Origin
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Compliance Standards | FCC Class A, UL, TUV GS, C-Tick, BSMI, cUL, CB, EMC, RoHS, WEEE, ANATEL, REACH, KCC Class A, LVD, VCCI Class A, MSIP Class A |
| Network Standards | IEEE 802.3, IEEE 802.1p |
Advanced Security Features
| Firewall Throughput | 6 Gbps |
| Full DPI Throughput | 1.2 Gbps |
| Application Throughput | 3 Gbps |
| IPS Throughput | 2.3 Gbps |
| Anti-Malware Throughput | 1.25 Gbps |
| SSL Throughput | 500 Mbps |
| VPN Throughput | 3 Gbps |
| Connection Rate | 40,000 connections per second |
| SPI Connections Supported | 3,000,000 |
| DPI Connections Supported | 1,000,000 |
| VPN Tunnels (Site-to-Site) | 4,000 |
| IPSec VPN Connections | 2,000 |
| SSL VPN Users | 2 |
| Virtual LAN Interfaces (VLANs) | 400 |
| SSO Users | 60,000 |
| Supported Routing Protocols | OSPF, RIP-1, RIP-2, BGP, static IP routing, policy-based routing (PBR) |
| Supported Network Protocols | TCP/IP, PPTP, UDP/IP, L2TP, ICMP/IP, IPSec, PPPoE, DHCP |
| Supported Encryption Algorithms | DES, 3DES, MD5, SHA-1, AES-128, AES-192, AES-256 |
| Authentication Methods | RADIUS, internal user database, XAUTH |
| Additional Security Features | NAT, VPN, load balancing, Stateful Packet Inspection, anti-spam, anti-malware, Deep Packet Inspection, intrusion prevention, DoS/DDoS prevention, URL filtering, policy-based routing, QoS, NetFlow/IPFIX, DHCP relay, DNS proxy, stateful switchover, LACP |
Interfaces
| 10Gb Ethernet (SFP+) | 2 ports |
| 2.5Gb Ethernet (SFP) | 4 ports |
| 2.5Gb Ethernet (RJ-45) | 4 ports |
| 1Gb Ethernet (RJ-45) | 16 ports |
| USB Type A | 2 ports |
| Console Port (RJ-45) | 1 port |
| Management Port (1Gb RJ-45) | 1 port |
| Expansion Slots | 1 (1 free) |
| Connectivity Technology | Wired |
| Data Link Protocols | Gigabit Ethernet, 10 Gigabit Ethernet, 2.5 Gigabit Ethernet |
Physical & Environmental
| Minimum Operating Temperature | 32 °F |
| Maximum Operating Temperature | 104 °F |
| Operating Humidity Range | 10 - 90% (non-condensing) |
Cloud Management & Licensing
| Included Licensing | 1 year TotalSecure Advanced Edition |
| Operating System | SonicOS 6.5.1 |
| Management Protocols | SNMP v2, SNMP v3, HTTP, HTTPS, CLI |
