SonicWall SWS14-24FPOE Managed 28-Port PoE+ Switch with 1YR Support

VENDOR: SONICWALL Mfg Part#: 02-SSC-8377 UPC#: 758479283775
1 3
Photo is for illustration purposes only. Actual product may be different.
$1,547.00
$1,547.00
Sale Sold out
MSRP: $1,751.00
Shipping calculated at checkout.
  • 28-port managed switch with 24 x PoE+ gigabit ports and 4 x 10G SFP+ uplinks
  • 410W total PoE budget supports high-density device deployments
  • Switching capacity of 128 Gbps with 512MB RAM and 128MB flash memory
  • Supports 4096 VLANs with static IP routing, ACLs, and QoS
  • Comprehensive management with CLI, SNMP v1/2c/3, HTTPS, and SSH
  • TAA compliant with high MTBF (157,763 hours) for enterprise-class reliability

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Supports high-throughput networking and device power delivery with 410W PoE+ across 24 GbE ports—ideal for VoIP, IP surveillance, and APs
  • Enables scalable infrastructure with 4 x 10G SFP+ uplinks and advanced VLAN/security management features
  • Includes 1 year of 24x7 technical support to ensure business continuity and expert assistance

Product Overview

The SonicWall SWS14-24FPOE is a powerful 28-port managed switch engineered for enterprise and SD-Branch networks. It integrates 24 PoE+ ports with a total 410W power budget, plus four 10 Gigabit SFP+ uplinks for high-speed expansion. With 128 Gbps switching capacity, 512MB RAM, and advanced VLAN/QoS features, it offers extensive configuration and monitoring via SNMP, CLI, and WNM. TAA compliant and built for high reliability, it includes 1-year 24x7 SonicWall support—ideal for critical infrastructure deployments.

Specifications

Product Overview
Device Type Switch - 28 ports - managed
Form Factor Rack-mountable 1U
Switching Capacity 128 Gbps
RAM 512 MB
Flash Memory 128 MB
Power Requirements AC 120/230 V (50/60 Hz)
Internal Power Supply Yes
Power Consumption (Operational) 500.4 Watt
MTBF 157,763 hours
Bundled Services 1 year 24x7 Support
Model Number SWS14-24FPOE
Manufacturer Part Number 02-SSC-8377

Wireless Features

Compliance & Origin
Country of Origin TAIWAN
TAA Compliant Yes
Certifications FCC Class A, UL, TUV GS, C-Tick, BSMI, cUL, CB, RoHS, KCC, WEEE, ANATEL, REACH, ICES Class A, LVD, EMC Class A, VCCI Class A, MSIP
Standards Compliance IEEE 802.1p, IEEE 802.3af, IEEE 802.1x, IEEE 802.1ab (LLDP), IEEE 802.3at

Advanced Security Features
Port-Based Authentication IEEE 802.1X
Access Control Lists (ACL) Supported
Storm Control Supported
BPDU Guard Supported
DHCP Snooping Supported
MAC Address Filtering Supported
RADIUS Support Yes

Interfaces
Total Ports 28
Ethernet Ports 24 x 10/100/1000Base-T RJ-45 PoE+
SFP+ Uplink Ports 4 x 10 Gigabit SFP+
Console Port 1 x RJ-45
MAC Address Table Size 32K entries
VLAN Capacity 4096 VLANs
Routing Protocol Static IP routing
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet

Physical & Environmental
Height 1.7 in
Width 17.3 in
Depth 10.2 in
Weight 8.6 lbs
Min Operating Temperature 32 °F
Max Operating Temperature 104 °F
Humidity Range (Operating) 10 - 95% RH
Min Storage Temperature -40 °F
Max Storage Temperature 158 °F

Cloud Management & Licensing
Management Interface CLI, SSH, HTTPS, SNMP v1/v2c/v3
Zero-Touch Deployment Supported
Cloud Management SonicWall Wireless Network Manager (WNM)
Supported Protocols SNMP, LLDP, RSTP, MSTP, DHCP client/relay/snooping
