StarTech PEX1PCI1 PCIe to PCI Adapter Card – Low Profile

VENDOR: STARTECH Mfg Part#: PEX1PCI1 UPC#: 065030834629
1 5
Photo is for illustration purposes only. Actual product may be different.
$73.00
$73.00
Sale Sold out
MSRP: $79.00
Shipping calculated at checkout.
  • Supports installation of half-height/low-profile PCI cards in PCI Express slots
  • External form factor adapter design for compact system integration
  • Connects through 1 x PCI Express x1 interface
  • RoHS compliant and TAA certified
  • Includes 2-year manufacturer warranty
  • Made in TAIWAN

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Perfect solution for businesses needing to run legacy PCI cards on newer PCIe-only systems, aiding hardware compatibility.
  • Compact dimensions and external form factor allow easy installation into desktops or workstations with limited space.
  • Backed by a 2-year warranty and TAA compliance, ensuring regulatory acceptance and long-term reliability.

Product Overview

Install half-height/low profile PCI interface cards in a standard PCI Express expansion slot - pci express to pci adapter card - pci express to pci converter - pcie to pci adapter

Specifications

Product Overview
Product Type Adapter Card
Form Factor Low Profile / Half-Height
Interface Type PCI Express x1
Host Bus PCI Express
Expansion Slot Type 32-bit PCI
Compatibility PCI 2.2 compliant
Color Green
Power Requirements Powered via PCI Express slot
Warranty 2 Years

Physical & Environmental
Width 2.8 in (71 mm)
Depth 5.3 in (135 mm)
Height 0.8 in (20 mm)
Operating Temperature 5°C to 50°C (41°F to 122°F)
Storage Temperature -25°C to 70°C (-13°F to 158°F)
Humidity 85% RH non-condensing
Product Weight 52 g (1.8 oz)
Enclosure Type Steel
Mounting Hardware Included Yes – Low-profile bracket included

Cloud Management & Licensing
Cloud Management

Interfaces
PCI Slots Supported 1 x 32-bit PCI
PCI Express Interface 1 x PCI Express x1 male connector
Data Transfer Rate Up to 132 MBps (PCI 32-bit @ 33 MHz)
Connector Type Standard PCI Slot (Female)
Connectivity Technology Wired
Port Interface Bandwidth 250 MBps per direction (PCIe x1 Gen 1)
Number of Interfaces 1

Compliance & Origin
RoHS Compliance Yes
TAA Compliant Yes
CE Certified Yes
FCC Compliant Yes
REACH Compliant Yes
Country of Origin Taiwan

Advanced Security Features
Hardware Security Features
