YAMAHA PGM1 Paging Station Microphone for MTX5-D/MRX7-D

VENDOR: YAMAHA Mfg Part#: PGM1 UPC#: 889025112123
1 4
Photo is for illustration purposes only. Actual product may be different.
$1,008.00
$1,008.00
Sale Sold out
MSRP: $1,684.00
Shipping calculated at checkout.
  • 8 programmable buttons configurable via MTX-MRX Editor
  • Compatible with Yamaha MTX5-D and MRX7-D processors
  • Compact design: 132(W) × 56(H) × 154(D) mm
  • Lightweight at 1.2 kg (including microphone)
  • Customizable input and output routing functions
  • Made in Indonesia for assured build quality

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Ideal integration with Yamaha MTX5-D and MRX7-D makes it a purpose-built solution for Yamaha audio infrastructures
  • Customizable control allows operators to streamline workflows with assigned functions for enhanced efficiency
  • Compact and durable construction ensures long-term use in commercial settings with limited space

Product Overview

The YAMAHA PGM1 Paging Station Microphone is a dedicated control interface engineered to deliver professional performance in commercial paging and audio routing systems. Specifically designed to work with compatible Yamaha digital signal processors—the MTX5-D and MRX7-D—the PGM1 functions as a versatile paging solution in corporate, educational, or hospitality environments. Users can assign up to eight programmable buttons to perform specific actions such as routing audio signals or selecting input sources, all configurable through Yamaha's MTX-MRX Editor software.

Constructed for durability and usability, the unit measures 132mm x 56mm x 154mm and weighs 1.2 kg including the mic. Manufactured in Indonesia, it allows integrators to create tailored paging solutions with minimal complexity. Ideal for professionals seeking reliable audio communication tools integrated into Yamaha’s digital ecosystems.

Specifications

Product Overview
Product Type Paging Station Microphone
Form Factor Desktop Microphone Unit with Gooseneck Mic
Weight (including microphone) 1.2 kg
Weight (excluding microphone) 1.0 kg
Power Supply PoE (IEEE 802.3af Class 3)
Power Consumption 6.5 W max
Mounting Options Desktop-mounted
Application Paging and control for Yamaha MTX/MRX systems

Wireless Features
Wireless Connectivity

Compliance & Origin
Country of Origin Indonesia
Certifications CE, FCC Part 15 Class A, VCCI Class A
RoHS Compliance Yes
Safety Standards UL62368-1, IEC62368-1, EN62368-1

Advanced Security Features
Network Security Dante-based with standard network segmentation support
User Access Control Configurable via MTX-MRX Editor (admin rights required)

Interfaces
Primary Interface RJ-45 (Dante/Power/Control)
Audio Protocol Dante (2-input channels)
Control Interface MTX-MRX Editor (via Dante network)
Programmable Buttons 8
Scroll Wheel Yes (for dynamic selections)
Status Indicators Button LEDs, Power/Status LEDs
Mic Connector XLR-4M type (fixed on gooseneck mic)

Physical & Environmental
Dimensions (W x H x D) 132 x 56 x 154 mm (excluding mic)
Gooseneck Microphone Length 295 mm
Operating Temperature 0°C to +40°C
Storage Temperature -20°C to +60°C
Operating Humidity 30% to 90% (no condensation)
Storage Humidity 10% to 95% (no condensation)
Housing Material Metal and ABS resin
Color Black
Included Accessories Gooseneck microphone, Euroblock connector, Owner’s Manual

Cloud Management & Licensing
Configuration Software MTX-MRX Editor
Network Protocol Dante audio/control network
Licensing Required No license required for base functionality
Integration Compatible with MTX5-D and MRX7-D DSPs
Custom Functions Button functionality configurable through software
