AMD EPYC 7763 64-Core Processor, 2.45 GHz, Socket SP3

VENDOR: AMD Mfg Part#: 100-000000312
1 5
Photo is for illustration purposes only. Actual product may be different.
$5,152.91
$5,152.91
Sale Sold out
MSRP: $7,890.00
Shipping calculated at checkout.
  • 64-core AMD EPYC processor with 128-thread capability
  • Base clock speed of 2.45 GHz, with max turbo frequency reaching 3.5 GHz
  • 256 MB L3 cache for high-speed data access
  • Socket SP3 compatibility and support for 8-channel DRAM
  • 280W TDP designed for high performance server environments
  • Non-TAA compliant, origin: Malaysia

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Ideal for virtualization and parallel workloads due to 64-core/128-thread architecture
  • High memory throughput enabled by 8-channel DRAM support and 256 MB L3 cache
  • Boosts performance scalability in data centers and HPC environments with up to 3.5 GHz turbo frequency

Product Overview

The AMD EPYC 7763 is a member of the Milan (EPYC 7003 series) server processor family, purpose-built for compute-intensive enterprise environments. With 64 cores and support for 128 threads, it is optimized for high-throughput parallel workloads such as virtualization, data analytics, and large-scale simulations. The processor operates at a base frequency of 2.45 GHz and can turbo boost up to 3.5 GHz for peak performance bursts.

Equipped with a massive 256 MB of L3 cache and using the Socket SP3 platform, the EPYC 7763 also supports 8-channel DRAM memory configurations for high memory bandwidth—ideal for memory-bound applications. It boasts a thermal design power (TDP) rating of 280 watts, appropriate for dense rack servers and workloads that push processing limits. Despite its processing power, the part does not feature TAA compliance, which may be relevant for government or compliance-sensitive installations.

This processor brings strong ROI in enterprise setups, offering an unmatched combination of core density, memory bandwidth, and scalability. Designed for mission-critical systems, it allows IT infrastructure to scale workloads efficiently, enhancing both performance and operational agility in virtualized and data-heavy computing tasks.

Specifications

Product Overview
Processor Type AMD EPYC 7763
Processor Series EPYC 7003 Series (Milan)
Processor Socket Socket SP3
Base Clock Speed 2.45 GHz
Max Turbo Frequency 3.5 GHz
Number of Cores 64
Number of Threads 128
Thermal Design Power (TDP) 280 Watts
Manufacturing Technology 7nm FinFET
Architecture Zen 3
Form Factor Server CPU

Physical & Environmental
Package Type Organic Land Grid Array
Die Size Not disclosed
Operating Temperature (Maximum) 95° C (Tcase)
Operating Temperature (Typical) 85° C (Tcase)
Cooling Solution Included No
Heatsink Compatibility 3rd Gen EPYC SP3-compatible heatsinks

Cloud Management & Licensing
vPro / Remote Management Not supported
Integrated Security Processor AMD Infinity Guard
Secure Boot Yes
Secure Memory Encryption (SME) Yes
Secure Encrypted Virtualization (SEV) Yes
Included Software None

Interfaces
Socket Type SP3
PCIe Version PCIe 4.0
PCIe Lanes Supported 128
Memory Interface 8-Channel DDR4
Memory Speed Support Up to 3200 MHz
Memory Type DDR4 Registered ECC
Max Memory Bandwidth 204.8 GB/s

Compliance & Origin
Country of Origin Malaysia
TAA Compliant No
RoHS Compliance Yes
ECC Memory Support Yes

Advanced Security Features
Hardware Root of Trust Yes
Memory Protection Secure Memory Encryption (SME)
Application Isolation Secure Nested Paging (SNP)
Side Channel Attack Mitigations Yes
Integrated Security AMD Infinity Guard with SEV-ES and SEV-SNP
