Products Memory, Storage and Components CISCO 240GB M.2 Boot SATA I...

CISCO 240GB M.2 Boot SATA Intel SSD UCS-M2-I240GB=

VENDOR: CISCO Mfg Part#: UCS-M2-I240GB=
1 3
Photo is for illustration purposes only. Actual product may be different.
$954.53
$954.53
Sale Sold out
MSRP: $1,726.24
Shipping calculated at checkout.
  • 240GB M.2 form factor ideal for boot use cases
  • SATA interface for broad compatibility and efficient data performance
  • TAA compliant for government and federally funded applications
  • COO: Manufactured in China or Taiwan

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Purpose-built as a boot drive for Cisco UCS systems, ensuring compatibility and system stability
  • TAA compliance makes it suitable for government deployments and regulated industries
  • Compact M.2 design allows installation in space-constrained server environments

Product Overview

The CISCO 240GB M.2 Boot SATA Intel SSD (UCS-M2-I240GB=) is a compact, boot-optimized storage solution for enterprise-grade servers. It uses a SATA interface and M.2 form factor, ideal for Cisco UCS systems. TAA compliance ensures eligibility for government procurement, and its dual-country production origin meets sourcing requirements. This SSD supports fast startup, reliability, and integration in secure environments, offering performance and efficiency in critical infrastructure setups.

Specifications

Product Overview
Type Solid State Drive (SSD)
Form Factor M.2 2280
Device Capacity 240 GB
Series Intel SATA SSD
Usage Application Boot Drive for Cisco UCS Servers
Interface SATA 6 Gb/s
Power Consumption (Active) 2.7 W (typical)
Power Consumption (Idle) 1.1 W (typical)
MTBF 2,000,000 hours
Reliability Rating (Mean Time Between Failures) 2 million hours
Endurance Rating 435 TBW
Encryption Support AES 256-bit encryption
Data Retention 5 years at 40°C
Power Loss Protection Yes (Firmware Enhanced)

Physical & Environmental
Dimensions (W x D x H) 22 x 80 x 3.5 mm
Weight 10 grams (approx.)
Operating Temperature 0°C to 70°C
Storage Temperature -40°C to 85°C
Operating Humidity 5% to 95% (non-condensing)
Vibration (Operating) 2.17 GRMS (5-700Hz)
Shock Resistance 1000 G / 0.5 ms

Advanced Security Features
End-to-End Data Protection Yes
Secure Erase Support Yes
SMART Monitoring Yes

Interfaces
Host Interface SATA III (6 Gbps)
Interface Connector M.2 B+M Key
Data Transfer Rate (Sequential Read) up to 550 MB/s
Data Transfer Rate (Sequential Write) up to 500 MB/s
Random Read IOPS (4KB) up to 80,000 IOPS
Random Write IOPS (4KB) up to 75,000 IOPS

Compliance & Origin
Country of Origin China / Taiwan
TAA Compliant Yes
RoHS Compliance Yes
Certifications CE, FCC, UL, TUV, VCCI
Halogen Free Yes
