Cisco 3945 Router Wired Gigabit Ethernet C3945-VSEC-CUBE/K9

VENDOR: CISCO Mfg Part#: C3945-VSEC-CUBE/K9
1 3
Photo is for illustration purposes only. Actual product may be different.
$10,769.32
$10,769.32
Sale Sold out
MSRP: $15,795.00
Shipping calculated at checkout.
  • Wired router with Gigabit Ethernet for high-speed data, transport, and switching
  • Supports interoperability using SIP, H.323, or MGCP for VoIP integration
  • Features Survivable Remote Site Telephony for network resilience
  • Includes dual remote management options: IPv6 and DHCP
  • TAA compliant and manufactured in the United States
  • Does not include processor or cellular technology

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Ideal for phased migration to IP telephony thanks to multi-protocol VoIP interoperability
  • Ensures robust voice services with Survivable Remote Site Telephony during WAN outages
  • Compliant with TAA standards and manufactured in the U.S., suited for government or enterprise use

Product Overview

The Cisco 3945 router offers wired connectivity using Gigabit Ethernet for data, transport, and switching, ideal for enterprise-scale deployments. It enables interoperability with SIP, H.323, and MGCP, supporting phased migration to IP telephony environments. Features such as Survivable Remote Site Telephony enhance continuity in distributed infrastructures. While TAA-compliant and U.S.-manufactured, this unit does not include a processor or cellular capabilities, and is best suited for specialized, configurable routing scenarios managed via IPv6 and DHCP.

Specifications

Product Overview
Product Type Integrated Services Router
Model Cisco 3945
Part Number C3945-VSEC-CUBE/K9
Form Factor Rack-mountable
Mounting Type 19-inch rack
Power Requirements AC 100-240V (50/60 Hz)
Power Consumption (Max) 260 Watts
Redundant Power Supply Support Yes (Optional external RPS)
Weight 12.7 kg (28 lb)

Wireless Features
Wi-Fi Support

Compliance & Origin
Country of Origin United States
TAA Compliant Yes
Certifications FCC Part 15 Class A, UL/CSA 60950-1, CE Mark, VCCI, RoHS

Advanced Security Features
Security Features Zone-based firewall, Secure VPN, Intrusion Prevention System (IPS), NAT, ACLs
VPN Support IPSec, SSL VPN, DMVPN
Content Filtering Optional (via Cisco IOS security features)
Voice Security SRTP/Voice Encryption, Secure SIP
Survivable Remote Site Telephony (SRST) Yes

Interfaces
Integrated WAN Ports 3 x Enhanced High-Speed WAN Interface Card (EHWIC) slots
Integrated Network Interface Modules 2 x Network Interface Module (NIM) slots
Integrated Services Module (ISM) Slots 1 x ISM slot
Service Module Slots 3 x service module slots
Gigabit Ethernet Ports 4 x 10/100/1000 Ethernet ports
USB Ports 2 x USB 2.0 ports
Console Ports 1 x RJ-45 console port, 1 x USB console port
Auxiliary Ports 1 x RJ-45 auxiliary port
Memory Slots 2 x DDR2 DIMM slots
Maximum Flash Memory 256 MB CompactFlash (expandable to 4 GB)
Maximum DRAM 2 GB
Interface Speed 10/100/1000 Mbps auto-sensing

Physical & Environmental
Dimensions (W x D x H) 43.8 x 50.5 x 8.9 cm (17.25 x 19.9 x 3.5 in)
Rack Units 2U
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Operating Humidity 5% to 85% non-condensing
Noise Level 63 dBA (typical)
Cooling Type Fan-based cooling

Cloud Management & Licensing
Management Interface CLI, Cisco Configuration Professional, SNMP, HTTP/HTTPS, Telnet
Licensing Model Feature-based licensing
Included Licenses UC and Border Element (CUBE) license
