Cisco 8010 Timing Interfaces Card (1PPS/10MHz) spare

VENDOR: CISCO Mfg Part#: 8000-TIC=
1 2
Photo is for illustration purposes only. Actual product may be different.
$137.05
$137.05
Sale Sold out
MSRP: $201.00
Shipping calculated at checkout.
  • Timing Interfaces Card designed for Cisco 8010 platforms
  • Supports 1 Pulse Per Second (1PPS) and 10MHz signals
  • Plug-in card form factor for ease of integration
  • Manufactured in Mexico
  • Complies with TAA (Trade Agreements Act)

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Purpose-built for Cisco 8010 systems, ensuring direct compatibility and optimal performance
  • Supports precise timing signals (1PPS and 10MHz) critical for synchronized network operations
  • TAA-compliant and Mexico-origin card suitable for regulated government and enterprise environments

Product Overview

The Cisco 8010 Timing Interfaces Card (1PPS/10MHz) spare is a plug-in module designed for precision network synchronization via 1PPS and 10MHz timing outputs. Built for the Cisco 8010 platform, it supports mission-critical timing functionality in carrier-grade networks. TAA compliance and country-of-origin Mexico make it suitable for government use. Its modular design and tool-less installation minimize downtime and boost serviceability, contributing to efficient deployment in latency-sensitive applications.

Specifications

Product Overview
Product Type Timing Interfaces Card
Form Factor Plug-In Card
Modular Design Yes
For Use With Cisco 8010
Weight 1.2 lb (approx.)
Hot Swappable Yes
Tool-less Installation Yes
Power Requirements Supplied by chassis backplane

Physical & Environmental
Width 1.18 in (30 mm)
Height 20.18 in (512.6 mm)
Depth 9.3 in (236 mm)
Operating Temperature 32 to 104°F (0 to 40°C)
Storage Temperature -40 to 158°F (-40 to 70°C)
Operating Humidity 5% to 85% (non-condensing)
Storage Humidity 5% to 95% (non-condensing)

Cloud Management & Licensing
Management Interface Managed by Cisco 8010 chassis controller
License Required No additional license required

Interfaces
Interface Type Timing Input/Output
Output Timing Signals 1PPS, 10MHz
Number of Timing Ports 2
Connector Type BNC
Signal Level (1PPS) TTL
Signal Level (10MHz) 50 Ohm Sine Wave @ +10 dBm
Impedance 50 Ohm
Data Rate 10 MHz (Clock Signal)

Compliance & Origin
Country of Origin Mexico
TAA Compliant Yes
RoHS Compliance Yes
Certifications CE, UL, FCC Part 15 Class A

Advanced Security Features
Tamper Detection No
Secure Boot Support No
