Cisco Catalyst 9105AX 2x2 MIMO Access Point, Remanufactured

VENDOR: CISCO Mfg Part#: C9105AXI-B-RF UPC#: 889728440295
  • Cisco Catalyst 9105AX Series REMANUFACTURED
1 1
Photo is for illustration purposes only. Actual product may be different.
$437.17
$437.17
Sale Sold out
MSRP: $641.19
Shipping calculated at checkout.
  • Supports 2.4 GHz and 5 GHz dual-band wireless frequencies
  • Delivers up to 1 Gbps data transfer rate using Gigabit Ethernet
  • Equipped with 2x2 MIMO technology for improved signal reliability
  • Comes with two Ethernet ports for flexible connectivity
  • Compact form factor: 5.9" x 5.9" x 1.18"
  • TAA compliant and includes a limited lifetime hardware warranty

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Offers solid enterprise-grade wireless performance with 2x2 MIMO and 1 Gbps throughput
  • TAA compliance ensures suitability for government or federally funded projects
  • Remanufactured model provides sustainability benefits and cost savings without compromising warranty coverage

Product Overview

The Cisco Catalyst 9105AX Series REMANUFACTURED access point delivers dual-band 2.4 GHz and 5 GHz support combined with 2x2 MIMO technology for high-density wireless coverage. With a 1 Gbps data rate over Gigabit Ethernet protocols, it supports demanding enterprise applications. Fully TAA compliant and manufactured in Mexico, this compact device includes two Ethernet ports and offers a limited lifetime hardware warranty, making it a smart choice for cost-effective and sustainable network upgrades.

Specifications

Product Overview
Product Type Access Point
Form Factor Ceiling mountable / Wall mountable
Environment Indoor
Mounting Options Wall, Ceiling
MIMO Type 2x2 MIMO
Data Transfer Rate 1 Gbps
Data Link Protocol Gigabit Ethernet
Transport Protocol Gigabit Ethernet
Power Requirements PoE (802.3af) or local power supply (optional)
Power Consumption (Maximum) 13.5W
Service & Support Type Limited lifetime hardware warranty

Wireless Features
Wi-Fi Standards 802.11a/b/g/n/ac/ax (Wi-Fi 6)
Wi-Fi Frequency Band Dual-band 2.4 GHz and 5 GHz
MU-MIMO Support Yes
Beamforming Yes (Transmit Beamforming)
Maximum Data Rate (5 GHz) 867 Mbps
Maximum Data Rate (2.4 GHz) 300 Mbps
Peak Aggregate Data Rate 1.2 Gbps
Number of Spatial Streams 2
Antenna Type Internal
Antenna Gain (2.4GHz) Peak 3.5 dBi
Antenna Gain (5GHz) Peak 4.0 dBi

Compliance & Origin
Country of Origin Mexico
TAA Compliance Yes
Certifications UL 60950-1, UL 62368-1, IEC 60950-1, IEC 62368-1, EN 60950-1, EN 62368-1, FCC Part 15.247, RSS-247
Regulatory Compliance RoHS, WEEE

Advanced Security Features
WLAN Security WPA3, WPA2, WPA, 802.1X
MAC Address Filtering Yes
Wireless Intrusion Detection (WIDS) Yes
Wireless Intrusion Prevention (WIPS) Yes
Rogue Access Point Detection Yes
Secure Boot Yes

Interfaces
Ethernet Ports 2 x 10/100/1000 Mbps
Uplink Port 1 x 10/100/1000BASE-T (Ethernet/PoE-In)
Downlink Port 1 x 10/100/1000BASE-T (Local LAN)
Console Port 1 x Micro USB
Bluetooth Interface Bluetooth Low Energy (BLE) 5.0

Physical & Environmental
Width 5.9 Inch
Depth 5.9 Inch
Height 1.18 Inch
Weight 1.0 lb (0.45 kg)
Operating Temperature 32°F to 122°F (0°C to 50°C)
Storage Temperature -22°F to 158°F (-30°C to 70°C)
Operating Humidity 10% to 90% (non-condensing)
Storage Humidity 5% to 90% (non-condensing)

Cloud Management & Licensing
Management Interface Cisco DNA Center / Web UI / CLI
Cloud-Managed Optional with Cisco DNA Cloud
Licensing Model Cisco DNA Subscription (optional)
Supported Management Protocols SNMP, Telnet, SSH, HTTP, HTTPS
