Cisco Catalyst 9200L-24PXG2Y-EDU 24-Port Managed Switch

VENDOR: CISCO Mfg Part#: C9200L-24PXG2Y-EDU
  • CATALYST 9200L 24-P,8XMGIG,16X1G,2X25G UPLINKS, K12. Designed for scalable enterprise access, the Cisco Catalyst 9200L-24PXG2Y-EDU offers advanced Layer 3 switching with high-performance uplinks and extensive PoE+ support for education and enterprise networks.
1 1
Photo is for illustration purposes only. Actual product may be different.
$5,878.33
$5,878.33
Sale Sold out
MSRP: $8,550.29
Shipping calculated at checkout.
  • 24 ports: 8 x multi-gigabit (up to 10GBase-T), 16 x PoE+ (10/100/1000), 2 x 25G uplinks
  • 370 W Power over Ethernet (PoE+) budget
  • 292 Gbps switching capacity (327 Gbps with stacking)
  • Layer 3 routing support with OSPF, EIGRP, PIM, and policy-based routing
  • Advanced management via SNMP, RESTCONF, NETCONF, YANG, CLI
  • Security features include 802.1x, MACsec, 128-bit AES encryption, FHS, secure boot
View full details

Key Benefits

Eye-Insights
  • Ideal for institutional deployments with academic pricing and K12 support
  • Designed for scalability and high availability with StackWise-80 stacking and optional redundant power
  • Comprehensive warranty and support package including limited lifetime hardware replacement

Product Overview

The Cisco Catalyst 9200L-24PXG2Y-EDU is a managed Layer 3 switch delivering enterprise-class access switching with vital security, resiliency, and operational efficiency. This 24-port model includes 8 multi-gigabit ports (up to 10GBase-T), 16 10/100/1000 PoE+ ports with a 370 W PoE budget, and 2 x 25G uplink ports. It supports stackable deployment using Cisco StackWise-80 technology with 80 Gbps stacking bandwidth.

It features a switching capacity of 292 Gbps (up to 327 Gbps with stacking) and a forwarding rate of 229.16 Mpps. The switch supports up to 16000 MAC addresses, ACLs, virtual networks, 1024 VLANs, and comprehensive Layer 2/3 routing protocols. Management is secure and flexible via SNMP, CLI, RESTCONF, and more, including 128-bit AES encryption. Optional redundant power and temperature control capabilities provide robust uptime.

With a limited lifetime warranty, next-business-day replacement, and energy-efficient design, this switch meets the demands of educational and enterprise networks with long-term performance and value.

Specifications

Primary Information
Network Device Type Switch
Data Transfer Rate 25 Gbps
Networking / Ports Qty Not Included
Data Link Protocol Gigabit Ethernet
RAM / Total Installed Size 2 GB
Flash Memory / Installed Size 4 GB
Power / Voltage Required 100 to 240 VAC

Network
Interfaces 24-port 8xmGig, 16x1G, 2x25G, PoE+

Special Feature
COO MEXICO / MALAYSIA / MEXICO
TAA compliance Yes

Interfaces / Ports
Interfaces 24-port 8xmGig, 16x1G, 2x25G, PoE+

Dimensions&Miscellaneous
Width 17.5 Inch
Depth 13.8 Inch
Height 1.73 Inch

UNSPSC Code
UNSPSC Code 43222612
