Cisco Catalyst 9404R 4-Slot Switch with DNA-A License

VENDOR: CISCO Mfg Part#: C9404R-48U-BNDL-A
1 3
Photo is for illustration purposes only. Actual product may be different.
$13,843.78
$13,843.78
Sale Sold out
MSRP: $20,304.23
Shipping calculated at checkout.
  • Rack-mountable 6U chassis with side-to-side airflow for optimal heat dissipation
  • Equipped with Cisco Catalyst 9400 Series Supervisor 1XL and 240 GB SSD
  • Supports optional N+N power redundancy via hot-plug internal power supplies
  • Includes 2 total line-card slots and 2 supervisor slots for modular expansion
  • Operates reliably in 23 °F to 113 °F temperature range with 10 - 95% humidity tolerance
  • Backed by a limited lifetime warranty with next-business-day replacement

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Designed for enterprise scalability with modular supervisor and line card architecture
  • Delivers enhanced system availability through optional N+N power redundancy support
  • Pre-installed Cisco DNA Essentials software streamlines management and security integration

Product Overview

The Cisco Catalyst 9404R is a modular enterprise-class switch engineered for high availability, scalability, and security. Housed in a 6U rack-mountable chassis with side-to-side airflow, it includes one supervisor module and one line card, supporting a total of four line card slots and two supervisor slots. Its key built-in component—a 240 GB SSD—enhances system reliability and performance. Supporting hot-plug internal power supplies and optional N+N redundancy, this switch ensures maximum uptime for mission-critical operations.

Compliant with a wide range of international standards such as FCC Part 15 and RoHS, the Catalyst 9404R is both reliable and environmentally responsible. Its operational temperature range from 23 °F to 113 °F and humidity tolerance up to 95% (non-condensing) make it suitable for rigorous data center environments. Designed with field-replacement in mind, it supports a next-business-day limited lifetime warranty. The included Cisco DNA Essentials license provides access to automation and advanced security features for streamlined network management.

This switch is an ideal core or aggregation layer solution for mid-size to large enterprise networks, offering investment protection through hardware redundancy and modular scalability. Installation flexibility, advanced software capabilities, and robust construction make it a dependable choice for professional networking needs.

Specifications

Product Overview
Product Type Modular Layer 3 Enterprise Core Switch
Form Factor Rack-mountable 6U
Built-in Storage 240 GB SSD
Slot Configuration 4 line card slots, 2 supervisor slots
Installed Modules 1 supervisor module, 1 line card
Maximum Modules Supported 4 line cards
Weight 37.92 lbs
Power Redundancy Optional
Power Redundancy Scheme N+N (with optional power supply)
Power Supply Hot-plug internal (not installed)
Fan Configuration Fan tray included

Wireless Features

Compliance & Origin
Country of Origin Mexico
TAA Compliance Yes
Certifications FCC CFR47 Part 15, ICES-003 Class A, CISPR 22 Class A, EN 55022 Class A, VCCI Class A, RoHS
Environmental Compliance RoHS compliant
Safety Compliance EN 60950-1, IEC 60950-1, CAN/CSA-C22.2 No. 60950-1

Advanced Security Features
Integrated Security MACsec-256 encryption supported (on select line cards)
Access Control 802.1X, VLAN ACLs, Port-based security
Threat Protection Cisco TrustSec, Encrypted Traffic Analytics
Application Visibility Cisco NetFlow, Flexible NetFlow
Secure Boot & Image Signing Yes
Software-Defined Access Supported with Cisco DNA

Interfaces
Expansion Slots 2 (total) / 2 (free) x line-card slot, 2 (total) / 1 (free) x supervisor slot
Port Scalability Dependent on line cards installed
Backplane Bandwidth Up to 480 Gbps per slot (with Supervisor 1XL)
System Bandwidth Up to 1.44 Tbps
Stacking Support No (modular architecture)

Physical & Environmental
Dimensions (W x D x H) 17.3 in x 16.3 in x 10.4 in
Minimum Operating Temperature 23 °F (-5 °C)
Maximum Operating Temperature 113 °F (45 °C)
Humidity (Operating) 10 - 95% non-condensing
Minimum Storage Temperature -40 °F (-40 °C)
Maximum Storage Temperature 158 °F (70 °C)
Humidity (Storage) 10 - 95% non-condensing
Airflow Direction Side-to-side
Rack Mount Type 19-inch standard rack

Cloud Management & Licensing
Management Platform Cisco DNA Center
License Type Cisco DNA Essentials
Included Licenses Cisco Catalyst 9400 DNA Essential License
License Duration Term based (duration specified at purchase)
Cloud Management Features Automation, network assurance, provisioning, telemetry
