Cisco Catalyst C8300-1N1S-6T Voice Router with NIM-PVDM-3

VENDOR: CISCO Mfg Part#: C8300-1N1S-6T-V
1 3
Photo is for illustration purposes only. Actual product may be different.
$4,981.60
$4,981.60
Sale Sold out
MSRP: $7,306.35
Shipping calculated at checkout.
  • Intel x86 CPU with 8 GB DRAM for efficient processing
  • 16 GB M.2 SSD and 8 GB flash storage for fast operations
  • 6 x 1-Gigabit Ethernet ports for flexible network connectivity
  • Supports IPv4, IPv6, MPLS, and RADIUS protocols for advanced routing
  • AES encryption capabilities for secure data transmission
  • Bundled with NIM-PVDM-3 module for voice processing

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Ideal for enterprises requiring integrated voice and data in one secure device, thanks to the included NIM-PVDM-3
  • Flexible deployment with 6 Gigabit Ethernet ports and protocol support including IPv6 and MPLS
  • TAA compliant hardware suitable for government and regulated industries

Product Overview

The Cisco Catalyst C8300-1N1S-6T Voice Router with NIM-PVDM-3 delivers enterprise-grade performance with robust Intel x86 processing, 8 GB DRAM, and 16 GB M.2 SSD. Supporting IPv4, IPv6, MPLS, RADIUS, and AES encryption, it's ideal for secure communication systems. The inclusion of six 1-Gigabit Ethernet ports and TAA compliance makes it suitable for diverse enterprise and government applications.

Specifications

Product Overview
Product Type Enterprise Branch Router
Series Cisco Catalyst 8300 Series
Model C8300-1N1S-6T
Processor Intel x86 4-core processor
Flash Memory 16 GB M.2 SSD
System Memory (RAM) 8 GB DDR4 DRAM
Form Factor 1RU rack-mountable
Power Supply AC, internal, redundant supported
Power Consumption 110W (typical)
Voice Module Included NIM-PVDM-3 for voice DSP

Wireless Features
Wireless Support Optional via external modules (not pre-installed)

Compliance & Origin
Country of Origin CHINA / MEXICO
TAA Compliance Yes
Certifications UL, CE, FCC, RoHS, REACH

Advanced Security Features
Encryption Support AES-256, 3DES, IPsec, SSL, TLS
VPN Support IPSec, DMVPN, FlexVPN
Firewall Features Zone-Based Policy Firewall (ZBFW)
Intrusion Prevention System Cisco IOS IPS (subscription required)
Content Filtering Cisco Umbrella integration (license required)
Malware Protection Cisco Threat Intelligence Director via Cisco DNA

Interfaces
Integrated Ethernet Ports 6 x 10/100/1000 Mbps RJ-45 ports
Service Module Slots 1 x SM-X module slot
Network Interface Module (NIM) Slots 1
Management Ports 1 x 10/100/1000 Mbps RJ-45, 1 x USB 3.0, 1 x mini-USB console port
Internal Storage 1 x M.2 SSD slot (populated)
Expansion Interface 1 x NIM slot, 1 x SM-X slot
Data Transfer Rate Up to 1 Gbps per port

Physical & Environmental
Dimensions (H x W x D) 1.72 x 17.2 x 17.5 in (4.36 x 43.7 x 44.5 cm)
Rack Units 1U
Weight Approximately 15.6 lbs (7.1 kg)
Operating Temperature 32°F to 104°F (0°C to 40°C)
Storage Temperature -40°F to 158°F (-40°C to 70°C)
Operating Humidity 5% to 85% non-condensing
Storage Humidity 5% to 95% non-condensing
Cooling Internal fans with front-to-back airflow
MTBF 672,896 hours

Cloud Management & Licensing
Management Interface Cisco IOS XE, Web UI, CLI, Cisco DNA Center
License Model Cisco Smart Licensing enabled
Included Features Voice DSP module, IOS XE software
Cloud Onboarding Supported via Cisco DNA Center
