Cisco Secure Firewall 4200 8-Port 1G Copper RJ45 Network Module

VENDOR: CISCO Mfg Part#: FPR4K-XNM-8X1GF=
1 3
Photo is for illustration purposes only. Actual product may be different.
$4,111.36
$4,111.36
Sale Sold out
MSRP: $6,030.00
Shipping calculated at checkout.
  • - 8-port RJ-45 interface supporting Gigabit Ethernet
  • - 1 Gbps data transfer rate per port
  • - Plug-in form factor for Cisco Secure Firewall 4200
  • - Wired connectivity for stable and secure transmission
  • - TAA-compliant and manufactured in Mexico

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • - Seamless integration with Cisco Secure Firewall 4200 enables scalable and efficient network security expansion
  • - 8-port Gigabit connectivity enhances throughput for high-performance enterprise environments
  • - TAA compliance and plug-in design support federal and regulated industry deployments

Product Overview

The Cisco Secure Firewall 4200 8-Port 1G Copper RJ45 Network Module is a plug-in expansion designed for the Cisco Secure Firewall 4200. It features eight RJ-45 ports with Gigabit Ethernet support for fast and secure wired connectivity. Engineered for scalable security deployments, it offers 1 Gbps throughput per port and complies with TAA regulations, making it suitable for government and enterprise environments. This plug-in network module from Mexico is built to integrate seamlessly into copper-based infrastructures, enhancing firewall performance and reducing network bottlenecks.

Specifications

Product Overview
Product Type Network Module
Manufacturer Cisco
Model Name Cisco Secure Firewall 4200 8-Port 1G Copper RJ45 Network Module
Manufacturer Part Number FPR4K-XNM-8X1GF=
Compatibility Cisco Secure Firewall 4200 Series
Form Factor Plug-In Module
Mounting Type Internal – for Firewall Expansion Slot
Type 8-Port Gigabit Ethernet Copper Network Interface Module
Connectivity Technology Wired
Power Requirements Powered via host device (Cisco Secure Firewall 4200)

Physical & Environmental
Dimensions Approx. 8.4 x 7.0 in (21.3 x 17.8 cm)
Weight Approx. 1.2 lbs (0.54 kg)
Operating Temperature 32°F to 104°F (0°C to 40°C)
Storage Temperature -40°F to 158°F (-40°C to 70°C)
Operating Humidity 10% to 90% (non-condensing)
Storage Humidity 5% to 95% (non-condensing)

Cloud Management & Licensing
Management Interface Managed via Cisco Secure Firewall Management Center
Cloud Management Support Yes, with Cisco Defense Orchestrator (CDO)
Licensing Model Requires corresponding Cisco Secure Firewall licenses
License Included No (sold separately)
Feature Activation Through Cisco Smart Licensing

Interfaces
Interface Type RJ-45
Port Count 8
Data Transfer Rate per Port 1 Gbps
Total Aggregate Throughput 8 Gbps
Interface Standard Gigabit Ethernet
Transport Protocol Gigabit Ethernet
Data Link Protocol Gigabit Ethernet
Media Type Supported Twisted Pair Copper
Interface Connector Type 8 x RJ-45

Compliance & Origin
Country of Origin Mexico
TAA Compliant Yes
Certifications RoHS, FCC, UL, CE
Lead-Free Status Compliant
WEEE Compliance Yes
REACH Compliance Yes

Advanced Security Features
Firewall Integration Enhances secure connectivity via Cisco Secure Firewall 4200
Traffic Segmentation Supports network segmentation through dedicated port configurations
Hardware Security Module (HSM) Support Supported via firewall system integration
Compliance Use Case Suitable for enterprise and government (TAA compliant markets)
