Products Memory, Storage and Components Eaton EPDU G3HD MA CS8365 4...

Eaton EPDU G3HD MA CS8365 40A 6ft, 39xC13 6xC19 Black PDU

VENDOR: EATON Mfg Part#: EMACPH36JJ2E4K2
1 5
Photo is for illustration purposes only. Actual product may be different.
$3,178.67
$3,178.67
Sale Sold out
MSRP: $4,091.00
Shipping calculated at checkout.
  • 40A power distribution unit with CS8365 6-ft input
  • Total of 45 outlets: 39x C13 and 6x C19 for equipment flexibility
  • 6x DP-20A distribution paths for high-density power delivery
  • TAA compliant and made in the United States
  • Vertical 49.6U form factor, measures 86.73 inches (2203 mm)
  • Black enclosure suitable for professional rack environments

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Delivers robust and scalable power distribution with 45 outlets, ideal for high-density rack setups.
  • Meets TAA compliance standards and is manufactured in the USA, ideal for regulated and federal environments.
  • Optimized for vertical integration into standard server racks with a 49.6U height and professional black finish.

Product Overview

Eaton EPDU G3HD MA CS8365 40A 6FT-END 6xDP-20A 39xC13,6xC19 LENGTH 86.73 inch /2203mm/49.6U, COLOR BLACK

Specifications

Product Overview
Product Type Power Distribution Unit (PDU)
Form Factor Vertical Rackmount (0U)
Cord Length 6 ft (1.83 m)
Power Rating 9.6 kW
Input Connector Type CS8365C (50A 250V 3P+N+G)
Output Voltage 208V
Color Black
Unit Length 86.73 in (2203 mm)
Rack Units 49.6U
Weight 19.8 lbs (9 kg)

Physical & Environmental
Mounting Type Vertical (tool-less button mount)
Material Aluminum chassis
Dimensions (H x W x D) 2203 mm x 56.5 mm x 66 mm
Operating Temperature 0°C to 60°C (32°F to 140°F)
Storage Temperature -25°C to 70°C (-13°F to 158°F)
Operating Humidity 5% to 95% non-condensing
Storage Humidity 5% to 95% non-condensing

Cloud Management & Licensing
Management Interface Web GUI, SNMPv1/v2/v3, Telnet/SSH CLI
Remote Monitoring Yes, via Eaton Intelligent Power Manager (IPM)
Authentication Protocols LDAP, RADIUS
Firmware Upgradeable Yes
User Access Controls Role-based access control (RBAC)

Interfaces
Total Output Receptacles 45
C13 Outlets 39
C19 Outlets 6
Number of Power Modules 6 (20A circuits)
Primary Input Plug CS8365C
Output Connector Type(s) IEC 60320 C13, IEC 60320 C19
PDU Switching Managed – individual outlet control
Metering Outlet-level power monitoring
Network Interface Gigabit Ethernet (RJ-45)

Compliance & Origin
Country of Origin United States
TAA Compliant Yes
Certifications UL/cUL 60950-1, FCC Class A, RoHS
Environment Standards RoHS compliant
REACH Compliance Yes

Advanced Security Features
Encrypted Access HTTPS, SSH
SNMPv3 Support Yes
Event Logging Yes
Alert Notification Email, SNMP traps
