Eaton Tripp Lite 72V EBM for 2200VA/3000VA SmartPro UPS, 2U Rack/Tower, TAA

VENDOR: EATON Mfg Part#: BP72VRXLTAA UPC#: 786689816049
1 3
Photo is for illustration purposes only. Actual product may be different.
$1,064.41
$1,064.41
Sale Sold out
MSRP: $1,720.00
Shipping calculated at checkout.
  • 72V output enhances runtime for select SmartPro 2200VA and 3000VA UPS systems
  • 2U rack/tower form factor for flexible deployment
  • TAA-compliant design suitable for government installations
  • RoHS compliant for environmental responsibility
  • Compact dimensions: 3.4 x 17.2 x 23.77 inches
  • Backed by a 2-year manufacturer warranty

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Provides critical backup extension for 2200VA/3000VA SmartPro UPS models, minimizing downtime during outages
  • Flexible 2U rack/tower configuration adapts to diverse IT environments for streamlined installation
  • TAA and RoHS compliance ensures suitability for government use and aligns with sustainability goals

Product Overview

Eaton Tripp Lite Series 72V Extended Battery Module (EBM) for Select 2200VA and 3000VA SmartPro UPS Systems, 2U Rack/Tower, TAA - 2-year warranty

Specifications

Product Overview
Product Type External Battery Module (EBM)
Model Name BP72VRXLTAA
Compatible UPS Models Eaton Tripp Lite SmartPro UPS 2200VA and 3000VA models
Form Factor 2U Rack/Tower
Weight 66.6 lb (30.2 kg)
Power Requirements Supplied by compatible UPS system
Nominal Output Voltage 72V
Battery Type Sealed Lead Acid (SLA), Valve-regulated, maintenance-free
Battery Quantity 6
Battery Voltage 12V per battery
Expandable Battery Runtime Yes (multiple modules supported)
Hot-Swappable No
Warranty 2-year limited warranty

Physical & Environmental
Dimensions (H x W x D) 3.4 x 17.2 x 23.8 inches (8.7 x 43.7 x 60.5 cm)
Rack Height 2U
Material Steel chassis
Color Black
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -15°C to 45°C (5°F to 113°F)
Operating Humidity 0% to 95% (non-condensing)
Storage Relative Humidity 0% to 95% (non-condensing)
Cooling Passive

Cloud Management & Licensing
Remote Management No (managed through compatible UPS)
Monitoring Support Indirect monitoring via UPS system
Bundled Software None
License Requirement No license required

Interfaces
Connection Type to UPS DC connector cable
Connectors Included Internal connection cable for compatible UPS
Battery Charger Included No (charges via compatible UPS)

Compliance & Origin
Country of Origin Taiwan
TAA Compliant Yes
RoHS Compliant Yes
Certifications UL 1778, cUL
Environment Standards ISO 9001 Certified
