Eaton UPS 93PM 480V 80kW Single Input w/ Comms & 3-Breaker MBS

VENDOR: EATON Mfg Part#: 9PG08C0029E20R2
1 1
Photo is for illustration purposes only. Actual product may be different.
$58,786.98
$58,786.98
Sale Sold out
MSRP: $91,072.00
Shipping calculated at checkout.
  • 480V single input configuration for industrial-grade power
  • 80kW power output suitable for high-demand critical systems
  • Includes all standard communication cards for remote monitoring
  • 3-breaker Maintenance Bypass Switch rated at 35kAIC
  • Manufactured in Finland with TAA compliance
  • Does not include batteries to permit storage solution flexibility

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Delivers 80kW power output at 480V, making it ideal for mission-critical operations.
  • Includes 3-breaker MBS rated at 35kAIC for safe and seamless maintenance without system downtime.
  • Comes with all communication cards pre-installed, enhancing monitoring and network integration capabilities.

Product Overview

Eaton UPS - 93PM 480v, 80kW single input, all communication cards, 3 breaker MBS 35kAIC, no batteries.

Specifications

Product Overview
Type Three-phase Online Double-Conversion UPS
Model Eaton 93PM 80kW
Form Factor Tower
Power Capacity 80 kW
Voltage Required 480 V (3-phase)
Input Voltage 480 V
Output Voltage 480 V
Power Factor 0.99 (input) / 1.0 (output)
Efficiency Up to 97%
Energy Saver System (ESS) Yes
Scalability Scalable via paralleling up to 4 units
Bypass Type Maintenance Bypass with 3 circuit breakers (3-breaker MBS)

Physical & Environmental
Dimensions (H x W x D) 78.7 x 23.6 x 39.4 in (2000 x 600 x 1000 mm)
Weight 1350 kg (2976 lbs) without batteries
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -25°C to 70°C
Relative Humidity 5% to 95%, non-condensing
Altitude (maximum operating) Up to 1000 m without derating
Noise Level <70 dBA at 1 meter

Cloud Management & Licensing
Cloud Management Support Eaton Intelligent Power Manager (IPM) compatibility
Network Management SNMP/Web Manager with HTML5 GUI
Licensing Requirements Basic features included; advanced IPM software license optional

Interfaces
Communication Slots 4 communication bays
Pre-installed Communication Cards Modbus RTU, Modbus TCP, SNMP/Web Card
Remote Emergency Power Off (REPO) Yes
USB Port 1 x USB for service access
Serial Port 1 x RS-232
Relay Output User configurable dry contacts

Compliance & Origin
Country of Origin Finland
TAA Compliant Yes
Certifications UL 1778, CSA C22.2 No. 107.3, CE Marked
Environmental Standards RoHS compliant
Seismic Rated IBC 2012, ASCE 7-10 (optional kit)
EMI/RFI Suppression IEC/EN 62040-2 Category C3

Advanced Security Features
Password Protection Yes (multi-level access control)
Syslog Support Yes
Event Logging Yes (internal memory and SNMP trap-based alerts)
