Extreme Networks 24VDC Industrial GbE PoE Injector, 30W, -40°C to +75°C, DIN Mount

VENDOR: EXTREME NETWORK INC Mfg Part#: 16806
1 5
Photo is for illustration purposes only. Actual product may be different.
$523.90
$523.90
Sale Sold out
MSRP: $754.00
Shipping calculated at checkout.
  • 30W PoE output with IEEE 802.3af/at compliance for reliable power delivery
  • Operating temperature range from -40°F to 167°F (-40°C to +75°C) for extreme environments
  • Supports 20–60V DC input with power redundancy capability
  • Gigabit LAN via 1 x RJ-45 port for high-speed data transfer
  • DIN rail and wall mountable for flexible installation
  • Certified to extensive industrial, EMC, and safety standards including IP30

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Operates in extreme temperatures, making it ideal for harsh industrial or outdoor environments
  • Supports high-power 30W PoE output for powering demanding network devices
  • Compact and DIN-mountable design simplifies deployment and saves space

Product Overview

24VDC GbE PoE injector with 30W output Operating Temperature -40C - +75C

Specifications

Product Overview
Product Type Industrial PoE Injector
Form Factor DIN rail mountable
Power Redundancy Yes
Power Capacity 30 Watt
Output Voltage 54 V
Max Electric Current 0.6 A
Input Voltage Range DC 20 - 60 V
Weight 12.34 oz
Mounting Options DIN rail, wall mount

Physical & Environmental
Width 1.2 in
Depth 3.9 in
Height 5.5 in
Minimum Operating Temperature -40 °F
Maximum Operating Temperature 167 °F
Humidity Operating Range 5 - 90% (non-condensing)
Enclosure Rating IP30

Cloud Management & Licensing
Cloud Management
Licensing Requirements
Bundled Cloud Features

Interfaces
Input Connectors 2 x 6-pin terminal block
Output Connectors 1 x RJ-45
LAN Port Type Gigabit Ethernet
LAN Port Count 1
LAN Port Speed 10/100/1000 Mbps
PoE Standard IEEE 802.3af / IEEE 802.3at

Compliance & Origin
Country of Origin Taiwan
TAA Compliant Yes
RoHS Compliant Yes
Certifications UL 60950-1, EN 60950-1, CSA C22.2 No. 60950-1-03, KCC, WEEE, FCC Part 15 Class A, CB, BSMI, CE, EN 55011, EN55024, EN 61000-6-2, CISPR 24, IEC 61000-4 Series, EMC 2014/30/EU, LVD 2014/35/EU, AS/NZS CISPR 32 Class A, CU, UL/CSA/IEC/EN 61010-2-201
