ExtremeSwitching X465i-48W Bundle 48-Port Managed Switch with PSU & SSD

VENDOR: EXTREME NETWORK INC Mfg Part#: X465I-48W-B1-S1 UPC#: 644728047277
1 2
Photo is for illustration purposes only. Actual product may be different.
$15,979.43
$15,979.43
Sale Sold out
MSRP: $22,998.00
Shipping calculated at checkout.
  • 48 x 10/100/1000 UPOE ports and 2 x 40 Gigabit QSFP+ uplinks
  • Switching bandwidth of 364 Gbps and forwarding rate of 270.8 Mpps
  • 815W PoE budget with UPOE support for high-powered devices
  • Supports advanced routing protocols: OSPF, BGP, MPLS, PIM-SM
  • Integrated 120 GB SSD and 8GB eMMC storage with 8 GB RAM
  • Stackable up to 8 units with 160 Gbps stacking bandwidth

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Delivers enterprise-class routing and switching with 364 Gbps capacity and advanced protocol support, ideal for high-demand edge networks
  • Includes 120 GB SSD and Insight Architecture for enhanced analytics, automation, and service deployment capabilities
  • Built-in 1100W PSU and 815W PoE budget support UPOE devices and offer optional power redundancy for maximum uptime

Product Overview

ExtremeSwitching X465i-48W Bundle includes X465i-48W 120GB SSD and one 1100W AC PSU FB (10941)

Specifications

Product Overview
Device Type Switch - 48 ports - L3 - managed - stackable
Form Factor Rack-mountable 1U
Power Requirements AC 120/230 V (50/60 Hz)
Power Redundancy Optional
Power Provided 1100 Watt
Installed Power Supply 1 x internal hot-plug power supply
Max Supported Power Supplies 2
Software Included ExtremeWare XOS Advanced Edge
Installed Storage 120 GB SSD, 8GB eMMC
Processor 1
RAM 8 GB
Rack Mounting Kit Included

Physical & Environmental
Width 17.3 in
Depth 19.2 in
Height 1.7 in
Min Operating Temperature 32 °F
Max Operating Temperature 113 °F
Operating Humidity Range 10 - 95% (non-condensing)
Min Storage Temperature -40 °F
Max Storage Temperature 158 °F
Storage Humidity Range 10 - 95% (non-condensing)
Cooling Front-to-rear airflow with 3 fans

Cloud Management & Licensing
Management Interface ExtremeCloud IQ (optional), CLI, Web UI, SNMP
Cloud Features Insight Architecture ready
Licensing Model Perpetual with upgrade options

Interfaces
10/100/1000 Ports 48 x RJ-45 (UPOE, 90W)
QSFP+ Ports 2 x 40GBase-X QSFP+
Management Port 1 x 1000Base-T RJ-45 management
Console Ports 1 x RJ-45, 1 x micro-USB Type B
USB Ports 2 x USB Type A
Expansion Slots 1 (total) / 1 (free)
Switching Bandwidth 364 Gbps
Forwarding Rate 270.8 Mpps
Stacking Bandwidth 160 Gbps
Maximum Stack Units 8
Jumbo Frame Support 9216 bytes

Compliance & Origin
Country of Origin MEXICO
TAA Compliance Yes
Compliant Standards IEEE 802.3ab, 802.3ae, 802.3aq, 802.3at, 802.3az, 802.3ba, 802.3bm, 802.3bz, 802.3bt, BSMI, IEC 61000 series, SABS, EN55024, CCC, EMC, ICES-003 Class A, UL, KCC, VCCI Class A, EAC, RoHS 2011/65/EU, WEEE 2012/19/EU, FCC CFR47 Part 15 A, LVD 2014/35/EU, EN/ETSI 300 019 series, ASTM D3580, ACMA RCM, China RoHS, CNS 15663

Advanced Security Features
MACsec Encryption Yes
Encryption Algorithm 128-bit AES, 256-bit AES
Supported Routing Protocols OSPF, RIP, BGP, PIM-SM, static IPv4, static IPv6, MPLS
Policy Profiles 63
User-created VLAN/VMANs 4092
IP Multicast Groups 4000
MAC Address Table Size 272K entries
