FORTINET FAP-432FR Outdoor Tri-Radio Wireless Access Point

VENDOR: FORTINET Mfg Part#: FAP-432FR-N
1 3
Photo is for illustration purposes only. Actual product may be different.
$1,473.13
$1,473.13
Sale Sold out
MSRP: $2,010.00
Shipping calculated at checkout.
  • Tri-radio design (1x 4x4 802.11ax 2.4GHz, 1x 4x4 802.11ax 5GHz, 1x 2x2 802.11ac Wave 2)
  • Supports both 2.4GHz and 5GHz frequency bands for greater flexibility
  • MU-MIMO 4x4 technology enhances wireless throughput and efficiency
  • 2.5 Gbps Ethernet port for high-speed wired connectivity
  • Bluetooth/BLE and Zigbee radios enable IoT integration
  • UL Class 1, Division 2 rating for use in hazardous industrial environments

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Ideal for industrial deployments thanks to UL Class 1, Division 2 hazardous location certification
  • Delivers superior wireless performance with tri-radio and 802.11ax/Wave 2 support
  • Includes multiple connectivity options (USB, serial, BLE, Zigbee) to support diverse devices and platforms

Product Overview

FORTIAP-432FR UL CLASS 1, DIVISION 2 .OUTDOOR WIRELESS FORTIAP - TRI RADIO (1X 802.11B/G/N/AX 4X4 RADIO, 1 X 802.11A/N/AC/AX 4X4 RADIO AND 1X 802.11 A/B/G/N/AC WAVE 2, 2X2), 1X 10/100/1000/2500 BASE-T RJ45, 1X 10/100/1000 BASE-T RJ45, BT/BLE + ZIGBEE, 1X TYPE A USB, 1X RS-232 RJ45 SERIAL PORT. EXTERNAL DUAL BAND N-TYPE OMNI DIRECTIONAL ANTENNAS, INTEGRATED MOUNTING BRACKET FOR ANTENNA INCLUDED + WALL/POLE MOUNT MOUNTING KIT. FOR POWER ORDER: 802.3AT POE INJECTOR GPI-130 OR AC ADAPTER SP-FAP400-PA. REGION CODE N

Specifications

Product Overview
Product Type Access Point
Model FAP-432FR
Form Factor Outdoor, Ruggedized
Mounting Options Wall or Pole Mount with Integrated Bracket
Weight 1.64 kg (3.62 lbs)
Power Consumption 25.5 W (maximum)
Power Options 802.3at PoE or AC Adapter (SP-FAP400-PA)
Radio Count Tri-Radio
Frequency Band 2.4 GHz and 5 GHz
MIMO Type 4x4 MU-MIMO (2 radios), 2x2 MIMO (1 radio)

Wireless Features
Wi-Fi Standards 802.11a/b/g/n/ac/ax (Wi-Fi 6)
Radio 1 4x4 MU-MIMO, 802.11b/g/n/ax (2.4 GHz)
Radio 2 4x4 MU-MIMO, 802.11a/n/ac/ax (5 GHz)
Radio 3 2x2, 802.11a/b/g/n/ac (Wave 2 monitor radio)
Max Data Rate 2.5 Gbps
Antenna Type External Dual Band Omni-directional N-Type Antennas
Number of Antennas 6 (External antennas required)
Beamforming Supported
Band Steering Supported

Compliance & Origin
Country of Origin Taiwan
RoHS Compliant Yes
Certifications FCC, CE, IC, UL, WEEE

Advanced Security Features
Security Integration Fortinet Security Fabric
Wireless IDS/IPS Supported via monitor radio
WPA3 Support Yes
Rogue AP Detection Yes
Application Control Yes (via FortiGate)

Interfaces
Networking Ports 1x 10/100/1000/2500 Base-T RJ45; 1x 10/100/1000 Base-T RJ45
Console Port 1x RJ45 Serial Console Port
USB Ports 1x USB Type A
Supported Interface Standards IEEE 802.3, 802.3u, 802.3ab, 802.3bz
Network Connectivity Gigabit Ethernet / 2.5G Ethernet
Bluetooth / IoT Radios Yes – Bluetooth BLE and Zigbee

Physical & Environmental
Width 8.23 in (209 mm)
Depth 8.23 in (209 mm)
Height 2.38 in (60.5 mm)
Operating Temperature -40°C to 65°C (-40°F to 149°F)
Operating Humidity 5% to 95% (non-condensing)
Enclosure Rating IP67
Mounting Kit Wall/Pole Mounting Kit Included
Hazardous Location Rating UL Class 1, Division 2 compliant

Cloud Management & Licensing
Cloud Management FortiCloud (optional)
Management Interface FortiGate Controller or FortiAP Cloud
Licensing Model Subscription based (for FortiCloud)
Zero-Touch Deployment Supported
