FORTINET FortiAP 432F Outdoor Tri-Radio Access Point

VENDOR: FORTINET Mfg Part#: FAP-432F-EO
1 3
Photo is for illustration purposes only. Actual product may be different.
$1,184.19
$1,184.19
Sale Sold out
MSRP: $1,610.00
Shipping calculated at checkout.
  • Tri-radio access with 4x4 MU-MIMO for enhanced wireless performance
  • Supports latest Wi-Fi 6 (802.11ax) and legacy 802.11 standards
  • 2.5 Gbps Ethernet port plus 1G port and RJ45 console interface
  • BLE and ZigBee radio support for IoT sensor/device integration
  • Outdoor rated design with omni-directional N-type antennas
  • Includes PoE injector, antenna mount system, and pole/wall mounting kit

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Supports tri-radio architecture (Wi-Fi 6 included), ensuring high-density, high-speed wireless deployments
  • Includes PoE injector and full mounting kit, simplifying installation and reducing hardware costs
  • Offers BLE and ZigBee support for seamless IoT integration in smart environments

Product Overview

The FORTINET FortiAP 432F is an industrial-strength outdoor access point with tri-radio architecture, supporting one 4x4 802.11b/g/n/ax radio, one 4x4 802.11a/n/ac/ax radio, and one 2x2 802.11a/b/g/n/ac Wave 2 radio, ensuring powerful RF performance across bands. Its 2.5 Gbps Ethernet interface and BLE/ZigBee integration position it strongly for high-throughput IoT-ready environments. Outfitted with external dual-band omni-directional antennas and a PoE injector, it arrives deployment-ready with mounting options and outdoor-rated design. This is a top-tier solution for educational, municipal, and enterprise outdoor networks.

Specifications

Product Overview
Product Type Access Point
Model FortiAP 432F
Manufacturer Part Number FAP-432F-EO
Form Factor Outdoor Mountable
Environment Outdoor
Radio Count Tri
MIMO Type 4x4 MU-MIMO
Max Power Consumption 37.9 Watt
Power Input 802.3at PoE+
Weight 2.1 lbs (0.95 kg)

Wireless Features
Wi-Fi Standards 802.11a/b/g/n/ac/ax
2.4 GHz Radio 4x4 802.11b/g/n/ax
5 GHz Radio 4x4 802.11a/n/ac/ax
Dedicated Scan Radio 2x2 802.11a/b/g/n/ac Wave 2
Frequency Band 2.4 GHz; 5 GHz
Connectivity Technology Wireless
Antenna Type External dual-band omni-directional
Number of Antennas 4 External Antennas
Beamforming Support Yes
Max Wireless Throughput 574 Mbps (2.4 GHz), 1.2 Gbps (5 GHz)

Compliance & Origin
COO TAIWAN
Certifications FCC, CE, IC, UL 2043, EN 60601-1-2
RoHS Y

Advanced Security Features
Wireless Intrusion Detection Yes (WIDS/WIPS)
Rogue AP Detection Supported
Wireless Firewall Integration FortiGate UTM integration
Client Visibility & Control Yes (with FortiGate controller)
Application Control Available via FortiGate
Integrated Authentication 802.1X, WPA2-Enterprise, WPA3

Interfaces
Data Transfer Rate 2.5 Gbps
Networking Type Ethernet
Data Link Protocol Gigabit Ethernet
Transport Protocol Gigabit Ethernet
Networking / Ports Qty 3
Port 1 Type 1x 100/1000/2500BASE-T (RJ-45), PoE-enabled
Port 2 Type 1x 100/1000BASE-T (RJ-45)
Bluetooth / IoT Port 1x BLE/ZigBee radio

Physical & Environmental
Width 8.23 Inch
Depth 8.23 Inch
Height 2.38 Inch
Mounting Options Wall and Pole Mount Included
Operating Temperature -40°C to 65°C (-40°F to 149°F)
Humidity Range 5% to 95% non-condensing
IP Rating IP67 Outdoor Rated
Enclosure Material Ruggedized UV-Stabilized Plastic

Cloud Management & Licensing
Management Interface FortiGate, FortiCloud, FortiWLM
Licensing Model Controller-managed with FortiGate or cloud-managed via FortiCloud
Cloud Features Included Zero-touch deployment, device visibility, configuration management
