Fortinet FortiWiFi-80F-2R-3G4G-DSL Security Appliance Bundle

VENDOR: FORTINET Mfg Part#: FWF-80F-2R-3G4G-DSL-D-BDL-809-12
1 3
Photo is for illustration purposes only. Actual product may be different.
$4,609.09
$4,609.09
Sale Sold out
MSRP: $6,293.70
Shipping calculated at checkout.
  • Dual-band wireless capability with 3x3 MIMO for 2.4 GHz and 5 GHz bands
  • Integrated LTE 3G/4G support with SMA antenna connectors
  • Supports up to 700,000 concurrent and 35,000 new sessions per second
  • Delivers 4.4 Gbps IPSec VPN throughput for secure remote access
  • Desktop form factor with 15 Gigabit Ethernet ports
  • Includes 1-year FortiCare Premium and FortiGuard Enterprise Protection

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Combines wireless, wired, and cellular WAN support in one device for deployment flexibility
  • Included 1-year subscription ensures premium support and real-time threat intelligence
  • High concurrent session capacity and VPN throughput support growing network demands

Product Overview

The Fortinet FortiWiFi-80F-2R-3G4G-DSL is a compact, high-performance network security appliance tailored for SMBs and remote locations. It offers dual-band Wi-Fi through a 3x3 MIMO antenna system and supports LTE 3G/4G connectivity with flexible SMA connectors. With Gigabit Ethernet support, it achieves 700,000 concurrent sessions and high VPN throughput (4.4 Gbps), ideal for secure remote operations. The unit includes 15 networking ports and consumes only 34.31 watts. This bundle also features 1-year FortiCare Premium and FortiGuard Enterprise Protection for dedicated support and advanced threat management.

Specifications

Product Overview
Product Type Network Device
Model FORTIWIFI-80F-2R-3G4G-DSL
Manufacturer Part Number FWF-80F-2R-3G4G-DSL-D-BDL-809-12
Form Factor Desktop
Max Power Consumption 34.31 Watt
Power / Voltage Required 100-240V
Concurrent Sessions 700000
New Sessions Per Second 35000
VPN IPSec Throughput 4.4 Gbps

Wireless Features
Wi-Fi Technologies 802.11a/b/g/n/ac
Frequency Band 2.4 GHz; 5 GHz
Radio Count Dual
MIMO Type 3x3 MIMO
Wireless Throughput Up to 1.3 Gbps (combined)
LTE Bands Supported Global LTE bands; specific bands dependent on region

Compliance & Origin
Country of Origin
TAA Compliance
Certifications FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB
RoHS Compliance Yes
WEEE Compliance Yes

Advanced Security Features
Firewall Throughput 10 Gbps
IPS Throughput 1 Gbps
NGFW Throughput 900 Mbps
Threat Protection Throughput 700 Mbps
SSL Inspection Throughput 810 Mbps
IPSec VPN Tunnels 200
SSL VPN Users (Max) 500
Firewall Type Stateful Inspection with Application Control
Malware Protection Yes, via FortiGuard
Web Filtering Yes, via FortiGuard
Intrusion Prevention System (IPS) Yes
Application Control Yes
Antivirus and Antispam Yes

Interfaces
Port Count 15
Interface Types Gigabit Ethernet, Wi-Fi, LTE (cellular)
Data Link Protocols Gigabit Ethernet, Wi-Fi
Transport Protocol Gigabit Ethernet
Antenna Type Detachable External Antenna
Antenna Connectors SMA

Physical & Environmental
Width 8.5 Inch
Depth 7 Inch
Height 2.4 Inch
Weight 2.78 lbs
Operating Temperature 32°F to 104°F (0°C to 40°C)
Storage Temperature -31°F to 158°F (-35°C to 70°C)
Humidity Range (Operating) 10%–90% non-condensing

Cloud Management & Licensing
Management Interface FortiOS with centralized cloud management via FortiManager or FortiCloud
Licensing Model Subscription-based
Included Services 1 Year FortiCare Premium and FortiGuard Enterprise Protection
