Products Memory, Storage and Components GIGABYTE B650 AORUS ELITE A...

GIGABYTE B650 AORUS ELITE AX ATX Motherboard, AMD B650, DDR5, Socket AM5

VENDOR: GIGABYTE Mfg Part#: B650 AORUS ELITE AX UPC#: 889523033623
1 4
Photo is for illustration purposes only. Actual product may be different.
$211.35
$211.35
Sale Sold out
MSRP: $219.99
Shipping calculated at checkout.
  • - AMD B650 chipset with support for Ryzen 7000 Series processors
  • - Socket AM5 and ATX form factor for wide system compatibility
  • - DDR5 memory support up to 128 GB, Non-ECC
  • - Realtek 2.5GbE LAN for high-speed networking
  • - Multiple USB interfaces including USB Type-C, USB 3.2 Gen 2
  • - Expansion options include PCI Express x16 slot and M.2 storage support

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Designed for compatibility with AMD Ryzen 7000 Series processors, ensuring future-ready performance.
  • Features DDR5 and PCIe x16 support for high-speed computing and expandability.
  • Comprehensive I/O includes 2.5GbE LAN, USB 3.2, HDMI, and DisplayPort for broad connectivity.

Product Overview

The GIGABYTE B650 AORUS ELITE AX is a high-performance ATX motherboard built to support AMD Ryzen 7000 Series processors with the latest AMD B650 chipset and Socket AM5. It features support for up to 128 GB of DDR5 memory, numerous USB 3.2 and Type-C ports, and onboard M.2 interface support. With a Realtek 2.5GbE LAN for fast networking and PCIe x16 expansion slot, the board is ideal for a broad range of enthusiast or professional applications. Its robust layout and advanced features make it a future-proof centerpiece for high-end builds.

Specifications

Product Overview
Type Motherboard
Form Factor ATX
Chipset AMD B650
Processor Socket Socket AM5
Supported Processors AMD Ryzen 7000 Series
Maximum RAM Supported 128 GB
Memory Technology DDR5
ECC Support Non-ECC
Audio Realtek Audio CODEC
Networking Realtek 2.5GbE LAN (2.5 Gbps/1 Gbps/100 Mbps)
Power Requirements 24-pin ATX main power connector, 8-pin + 4-pin ATX 12V power connectors
Weight 1.1 kg

Wireless Features
Wireless LAN Wi-Fi 6E 802.11ax
Bluetooth Bluetooth 5.2
Antenna Type 2T2R external antennas (via SMA connectors)
Wi-Fi Frequency Bands 2.4 GHz, 5 GHz, 6 GHz

Compliance & Origin
Country of Origin China
RoHS Compliance Yes
Certifications CE, FCC, BSMI, KC

Advanced Security Features
Firmware Security Trusted Platform Module (TPM) header
Boot Protection Secure Boot supported
BIOS Guard DualBIOS with recovery support

Interfaces
USB Ports (Total) 12
Rear USB Ports 1 x USB 3.2 Gen 2x2 Type-C, 3 x USB 3.2 Gen 2 Type-A, 4 x USB 3.2 Gen 1, 4 x USB 2.0/1.1
Internal USB Headers 1 x USB 3.2 Gen 1 header, 2 x USB 2.0 headers
Ethernet Port 1 x RJ-45 (2.5GbE)
Video Outputs 1 x HDMI, 1 x DisplayPort
Audio Ports 3 x 3.5mm audio jacks
Expansion Slots 1 x PCIe 4.0 x16, 1 x PCIe 3.0 x16 (x4 mode), 2 x PCIe 3.0 x1
M.2 Slots 3 x M.2 (Socket 3, M Key)
SATA Ports 4 x SATA 6Gb/s
Fan Headers 4 x system fan headers, 1 x CPU fan header, 1 x pump header

Physical & Environmental
Width 30.5 cm
Depth 24.4 cm
Operating Temperature 0°C to 60°C
Storage Temperature -40°C to 70°C
Relative Humidity (Operating) 10% to 90% non-condensing

Cloud Management & Licensing
BIOS Management UEFI BIOS with Q-Flash and BIOS Flashback
Cloud Features GIGABYTE Control Center software suite
Licensing Requirements None (hardware-based management)
