HighPoint SSD7105 PCIe 3.0 x16 4x M.2 NVMe RAID Controller

VENDOR: HIGHPOINT TECHNOLOGIES, INC. Mfg Part#: SSD7105 UPC#: 643653710515
1 4
Photo is for illustration purposes only. Actual product may be different.
$299.00
$299.00
Sale Sold out
Shipping calculated at checkout.
  • PCIe 3.0 x16 interface for high throughput
  • Supports 4x M.2 NVMe SSDs for maximum performance
  • RAID levels 0, 1, 10, and single drive supported
  • Compatible with Windows, Linux, and macOS environments
  • Full-height design with dimensions of 8.27" x 5" x 0.83"
  • RAID management via WebGUI, CLI, BIOS, and UEFI interfaces

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Delivers ultra-fast NVMe storage with RAID flexibility across multiple OS platforms
  • Bootable RAID capability enhances system performance and startup workflows
  • Multi-interface management allows seamless RAID configuration in diverse IT environments

Product Overview

The HighPoint SSD7105 is a professional-grade PCIe 3.0 x16 RAID controller engineered for high-speed storage via four M.2 NVMe SSDs. Supporting RAID levels 0, 1, 10, and single drive modes, it enables fast, flexible storage architecture for advanced computing needs. Compatible with Windows, Linux, and macOS, the card offers full-height design and multi-environment RAID management through WebGUI, CLI, BIOS, and UEFI. Ideal for performance-critical systems, the SSD7105 balances speed, scalability, and integration flexibility.

Specifications

Product Overview
Product Type RAID Controller
Manufacturer HIGHPOINT TECHNOLOGIES, INC.
Model SSD7105
Form Factor Full-Height
Interface Type PCI Express 3.0 x16
RAID Levels Supported RAID 0, 1, 10, Single Drive
Power Consumption Up to 27.1W
Supported Operating Systems Windows 11/10, Windows Server 2022/2019/2016/2012 R2, Linux, macOS
Weight 180g

Cloud Management & Licensing
Management Interfaces WebGUI, Command Line Interface (CLI), UEFI, BIOS
RAID Management Software HighPoint Web RAID Management (WebGUI)
Cloud Management Support No native cloud integration
Licensing Requirements None (native software included)

Physical & Environmental
Dimensions (W x D x H) 8.27 x 5 x 0.83 inches
Cooling Active cooling (aluminum heatsink with fan)
Operating Temperature 0°C to 50°C
Storage Temperature -40°C to 85°C
Operating Humidity 5% to 60% non-condensing
Storage Humidity 5% to 95% non-condensing

Wireless Features

Interfaces
Host Interface PCIe 3.0 x16
Device Interface M.2 NVMe
Number of M.2 Ports 4
Supported M.2 Form Factors 2280, 22110
Data Transfer Rate Up to 14,000 MB/s aggregate
Hot-Swap Support No

Advanced Security Features
Bootable RAID Support Yes
Drive Encryption Support Depends on drive capabilities
Secure Boot Support Yes

Compliance & Origin
Country of Origin China
TAA Compliant No
RoHS Compliance Yes
CE Certification Yes
FCC Certification Yes
