Products Network Stuff HP Aruba 8360-16Y2C Power B...

HP Aruba 8360-16Y2C Power Bundle JL703A#ACQ Switch

VENDOR: HP Mfg Part#: JL703A#ACQ UPC#: 190017404523
1 3
Photo is for illustration purposes only. Actual product may be different.
$26,090.44
$26,090.44
Sale Sold out
MSRP: $32,955.00
Shipping calculated at checkout.
  • TAA compliant for regulated and government environments
  • Manufactured in Singapore for high-quality assurance
  • Part of the HP Aruba 8360 switch series
  • Includes bundled components, likely for enhanced power and port integration

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Ideal for public sector and enterprise environments due to TAA compliance
  • Manufactured in Singapore, ensuring stringent quality and production standards
  • Part of Aruba's 8360 series, tailored for performance-driven network infrastructures

Product Overview

The HP Aruba 8360-16Y2C Pwr2Prt3F2PS Bdl, part number JL703A#ACQ, is a powerful switch designed for enterprise network infrastructures. It is TAA compliant, making it well-suited for government-level procurements and regulatory environments. With its origin in Singapore, this product reflects high manufacturing standards. Though specific data like throughput and port speeds are not disclosed, its bundle configuration and integration within HP Aruba's 8360 series strongly suggest high scalability, resiliency, and efficient power management. Ideal for enterprise-level deployments, it offers reliable performance for mission-critical operations.

Specifications

Product Overview
Product Type Layer 3 Network Switch
Form Factor 1U Rack-mountable
Model Aruba CX 8360-16Y2C
Power Supply Dual Field Replaceable Power Supplies (AC)
Bundle Includes Switch with power supplies and fans
Switching Capacity 2.8 Tbps
Forwarding Rate 1,309 Mpps
Redundant Fans Yes (hot-swappable)
Operating System Aruba AOS-CX
Fans Included Yes (2 included)
Power Consumption (Typical) 150W
Weight 10.5 lbs (4.76 kg)

Wireless Features
Wireless Support Not applicable

Compliance & Origin
Country of Origin Singapore
TAA Compliant Yes
Certifications UL, CB, FCC Class A, VCCI, BSMI, CCC, CE, RoHS
Safety Approvals CAN/CSA-C22.2 No. 62368-1, UL 62368-1
EMC Standards EN 55032 Class A, EN 55024, EN 300 386

Advanced Security Features
Access Control 802.1X, MAC Authentication, Web-Based Authentication
Layer 2 Security DHCP Snooping, Dynamic ARP Protection
Secure Management HTTPS, SSH, SNMPv3
MACsec Supported on front ports
Role-Based Access Control Yes
ACL Support Yes (stateful and stateless ACLs)

Interfaces
Total Ports 18
40/100G QSFP28 Ports 16
1/10G SFP+ Ports 2
Management Port 1 x RJ-45 (out-of-band)
Console Port 1 x RJ-45 / 1 x USB-C
Expansion Slots None
Throughput Up to 2.8 Tbps switching capacity
Data Transfer Rate Up to 100 Gbps per port (QSFP28)

Physical & Environmental
Dimensions (WxDxH) 17.48 x 15.75 x 1.73 in (444 x 400 x 44 mm)
Operating Temperature 0°C to 45°C (32°F to 113°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Humidity (Operating) 5% to 95% non-condensing
Acoustic Noise 49.4 dB (Typical)
Heat Dissipation 512 BTU/hr

Cloud Management & Licensing
Management Interface Aruba Central, REST API, CLI, Web GUI
Licensing Requirements ArubaOS-CX Foundation or Advanced License (Sold Separately)
Included Features Basic L3 Routing, Static and RIP, OSPF, BGP with license
Remote Management Yes via Aruba Central
