Products Memory, Storage and Components HPE 1.6TB NVMe MU SFF BC U....

HPE 1.6TB NVMe MU SFF BC U.3 CM7 SSD

VENDOR: HP Mfg Part#: P63845-B21
1 1
Photo is for illustration purposes only. Actual product may be different.
$3,299.00
$3,299.00
Sale Sold out
Shipping calculated at checkout.
  • 2.5" NVMe SSD with U.3 interface for high-speed data access
  • 1.6TB capacity supporting mixed-use enterprise workloads
  • Up to 1,242,113 IOPS (random read) and 318,187 IOPS (random write)
  • Endurance rating of 3 Drive Writes Per Day (DWPD)
  • 18W power consumption during operation
  • TAA compliant and includes 3/0/0 manufacturer warranty

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Optimized for mixed-use workloads with high IOPS support, ideal for virtualization and database applications
  • 3 DWPD endurance ensures long-term reliability in write-intensive environments
  • Hot-swappable and TAA-compliant design supports efficient deployment in compliant and scalable enterprise systems

Product Overview

The HPE 1.6TB NVMe MU SFF BC U.3 CM7 SSD (P63845-B21) delivers exceptional performance with up to 1,242,113 IOPS random reads and 318,187 IOPS random writes. Designed in a 2.5-inch form factor with NVMe interface, it integrates efficiently into modern enterprise environments. The drive's 3 DWPD endurance supports write-intensive applications, while 18W power consumption balances performance with energy efficiency. Supporting hot-swap functionality, TAA compliance, and backed by a 3/0/0 warranty, it is ideally suited for scalable, high-performance data center deployments.

Specifications

Product Overview
Manufacturer HP
Product Name HPE 1.6TB NVMe MU SFF BC U.3 CM7 SSD
Manufacturer Part Number P63845-B21
Type Enterprise Solid State Drive (SSD)
SSD Capacity 1.6 TB
Form Factor 2.5-inch Small Form Factor (SFF)
Drive Write Per Day (DWPD) 3 DWPD
Power Consumption (Operational) 18 Watt
Weight 0.68 Kg
Hot Swap Support Yes
Warranty 3/0/0 warranty

Physical & Environmental
Width 8.63 inch
Depth 9 inch
Height 5.75 inch
Operating Temperature 0°C to 60°C
Non-Operating Temperature -40°C to 85°C
Operating Humidity 5% to 95% (non-condensing)
Vibration (Operating) 2.17 G (5–800 Hz)
Vibration (Non-Operating) 3.13 G (10–500 Hz)
Shock (Operating) 1000 G (0.5 ms half sine)

Cloud Management & Licensing
Cloud Integration

Interfaces
Interface Type NVMe
NVMe Version PCIe Gen4 x4
Connector U.3
Read IOPS (4KB Random) 1,242,113 IOPS
Write IOPS (4KB Random) 318,187 IOPS

Compliance & Origin
TAA Compliant Yes
Country of Origin Mexico
RoHS Compliance Yes
Certifications CE, FCC, VCCI, KC, BSMI, RCM

Advanced Security Features
Data Encryption AES 256-bit encryption
Power Loss Protection Yes
Secure Erase Yes
Drive Sanitization Digital Secure Erase
