HPE 48-Port WW Serial Console Server, 1U Rackmount, Q1P53A

VENDOR: HP Mfg Part#: Q1P53A UPC#: 190017146645
1 5
Photo is for illustration purposes only. Actual product may be different.
$7,525.47
$7,525.47
Sale Sold out
MSRP: $8,979.00
Shipping calculated at checkout.
  • 48 serial port access via DB9-RJ45 adapter
  • Gigabit Ethernet transport and data link protocol
  • 1U rackmount form factor with 1.75-inch height
  • Includes power jumper cable for deployment
  • TAA compliant and backed by a 3-year warranty
  • Manufactured in Mexico for assured quality and compliance

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Ideal for data centers needing secure remote device management via 48 serial ports.
  • 1U rackmount design optimizes space without compromising functionality.
  • Gigabit Ethernet support meets high-speed infrastructure demands.

Product Overview

The HPE 48-Port WW Serial Console Server (Q1P53A) offers centralized, out-of-band management in a compact 1U rackmount form factor. It supports up to 48 serial device connections and features Gigabit Ethernet connectivity for high-speed access. With a DB9-RJ45 adapter, power jumper cable, and compliance with TAA standards, this unit is ideal for enterprise or government infrastructure. Covered by a 3-year warranty and manufactured in Mexico, it ensures reliable and secure network management.

Specifications

Product Overview
Product Type Serial Console Server
Form Factor 1U Rackmount
Weight 5.2 lbs (2.36 kg)
Power Requirements 100-240 VAC, 50/60 Hz
Power Supply Type Internal (AC)
Mounting Type Rack-mountable
Number of Devices Supported 48

Wireless Features
Wi-Fi Support

Compliance & Origin
Country of Origin Mexico
TAA Compliant Yes
Certifications UL, CE, FCC Part 15 Class A, VCCI Class A
RoHS Compliant Yes
WEEE Compliance Yes

Advanced Security Features
User Authentication LDAP, RADIUS, TACACS+, Local
Access Control Role-based access control (RBAC)
Encryption Protocols SSL, SSH v2
Firewall Capabilities Basic packet filtering
Audit Logging Yes (Event and System logs)

Interfaces
Serial Console Ports 48 x RJ45
Management Ports 1 x RJ45 Console, 1 x DB9 (via adapter)
USB Ports 2 x USB 2.0
Ethernet Ports 2 x Gigabit Ethernet (RJ-45)
Port Type RJ45 (Serial); RJ45 (Ethernet)
Data Transfer Rate 10/100/1000 Mbps

Physical & Environmental
Width 17.25 in (43.8 cm)
Depth 9.5 in (24.1 cm)
Height 1.75 in (4.45 cm)
Rack Units 1U
Operating Temperature 0°C to 50°C (32°F to 122°F)
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Operating Humidity 20% to 80% (non-condensing)
Storage Humidity 5% to 95% (non-condensing)
Cooling System Fanless

Cloud Management & Licensing
Management Interface Web UI, SSH, SNMP, Telnet
Remote Management Protocols HTTPS, SSH, CLI
License Requirement No license required for basic features
Authentication Methods RADIUS, TACACS+, LDAP, Local
Logging & Monitoring Syslog, SNMP traps
