Products Memory, Storage and Components ISW AC-DC Power Supply 960W...

ISW AC-DC Power Supply 960W DIN Rail –30 to 70°C

VENDOR: EXTREME NETWORK INC Mfg Part#: ISW-AC-DC-PS-960W UPC#: 644728057993
1 1
Photo is for illustration purposes only. Actual product may be different.
$1,733.57
$1,733.57
Sale Sold out
MSRP: $2,495.00
Shipping calculated at checkout.
  • 960-watt AC-DC power output for high-performance systems
  • DIN rail-mountable design for industrial enclosures
  • Wide operating temperature range of –30°C to 70°C
  • TAA compliant for regulated or government use
  • Country of origin: Taiwan

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Delivers reliable high-capacity 960W output suitable for industrial and enterprise networking hardware.
  • Supports extreme environmental conditions (–30°C to 70°C), ideal for rugged or remote applications.
  • TAA compliance meets procurement requirements for government and regulated sectors.

Product Overview

ISW AC-DC Power Supply 960W Output DIN Rail -30 - 70C

Specifications

Product Overview
Product Type AC-DC Power Supply
Form Factor DIN Rail Mountable
Output Power 960 W
Input Voltage Range 85 to 264 VAC / 90 to 375 VDC
Output Voltage 24 VDC
Output Current 40 A
Power Efficiency Up to 95%
Cooling Type Internal Fan
Redundancy Support Yes

Physical & Environmental
Operating Temperature -30°C to +70°C
Storage Temperature -40°C to +85°C
Operating Humidity 5% to 95% (non-condensing)
MTBF Over 300,000 hours at 25°C (MIL-HDBK-217F)
Dimensions (W x H x D) 125 mm x 125 mm x 130 mm
Weight 2.9 kg
Cooling Method Forced Air via Built-in Fan
Housing Material Metal with Ventilation Slots
Installation Orientation Vertical on DIN Rail
Shock Resistance IEC 60068-2-27 (30G)
Vibration Resistance IEC 60068-2-6 (10-500Hz, 2G)

Cloud Management & Licensing
Remote Monitoring Support No
Management Interface
Licensing Requirements None

Interfaces
Input Connection Type Screw Terminal Block
Output Connection Type Screw Terminal Block
Remote ON/OFF Control Yes
Signal Output DC OK Relay & LED Indicator
Current Sharing Function Yes, Parallel Operation Up to 4 Units

Compliance & Origin
Country of Origin Taiwan
TAA Compliant Yes
Certifications UL 508, EN60950-1, EN62368-1, CE, CB, RoHS
EMI Compliance EN55032 Class B, EN61000-3-2
EMS Compliance EN61000-4-2,3,4,5,6,8,11
Ingress Protection IP20
Pollution Degree 2

Advanced Security Features
Overvoltage Protection Yes
Overcurrent Protection Yes
Overtemperature Protection Yes
Short Circuit Protection Yes
