Lenovo 3.5" P5620 1.6TB MU NVMe SSD

VENDOR: LENOVO Mfg Part#: 4XB7A17141
1 5
Photo is for illustration purposes only. Actual product may be different.
$4,909.00
$4,909.00
Sale Sold out
Shipping calculated at checkout.
  • 3.5-inch form factor for broader hardware compatibility
  • NVMe interface for high-speed data transfer and low latency
  • 1.6TB storage capacity suitable for enterprise workloads
  • Designed for mixed-use (MU) applications requiring balanced endurance and performance
  • Lenovo enterprise-grade manufacturing and integration standards

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • High-speed NVMe interface enhances system responsiveness and reduces bottlenecks in data-intensive workflows.
  • Large 1.6TB capacity supports massive datasets and reduces the need for frequent storage upgrades.
  • Lenovo engineering assurance ensures compatibility and performance in enterprise IT environments.

Product Overview

The Lenovo 3.5" P5620 1.6TB MU NVMe SSD is a robust storage solution tailored for performance-critical environments. Featuring a spacious 1.6 terabyte capacity, this solid-state drive allows for efficient handling of large data sets, making it well-suited for enterprise-level servers, databases, and virtualized environments. Its 3.5-inch form factor provides compatibility with a wide range of server and workstation enclosures that support this size profile.

Utilizing a high-speed NVMe interface, the P5620 SSD minimizes latency while maximizing data transfer speeds, creating a significant performance boost over traditional SATA-based drives. Designed for mixed-use (MU) workloads, this SSD balances durability with throughput, making it appropriate for applications where performance and reliability are both critical. Manufactured by Lenovo, the drive benefits from rigorous testing and integration assurance within Lenovo’s enterprise systems.

While features like country of origin and TAA compliance are listed as “Inquire,” the product's specifications indicate its primary use cases in IT infrastructures where speed and dependable storage access are key. It's recommended for IT professionals seeking scalability and performance in demanding computing tasks.

Specifications

Product Overview
Type Enterprise NVMe SSD
Form Factor 3.5"
Use Case Mixed Use (MU) Workloads
Capacity 1.6 TB
Interface NVMe PCIe 4.0 x4
Endurance (Drive Writes Per Day) 3 DWPD
Sequential Read Performance up to 7000 MB/s
Sequential Write Performance up to 4300 MB/s
Random Read IOPS (4K) up to 1,000,000 IOPS
Random Write IOPS (4K) up to 160,000 IOPS
MTBF 2,000,000 hours
Power Loss Protection Yes
Hot Swap Support Yes
Power Consumption (Active) up to 14W
Power Consumption (Idle) 5W

Physical & Environmental
Form Factor Name U.2 (2.5" SSD housed in 3.5" carrier)
Device Dimensions (with bracket) 147 mm x 101 mm x 25 mm
Weight 0.6 kg (approx.)
Operating Temperature Range 0°C to 70°C
Storage Temperature Range -40°C to 85°C
Operating Humidity 5% to 95% (non-condensing)
Shock Resistance 1000 G @ 0.5 ms half sine
Vibration (Operating) 2.17 G rms @ 7-800 Hz
Vibration (Non-Operating) 3.13 G rms @ 7-800 Hz

Cloud Management & Licensing
Management Interface Lenovo XClarity (when integrated)
Firmware Management Tool-less firmware updates (via Lenovo systems)
Cloud Monitoring Support Supported on Lenovo enterprise platforms

Interfaces
Interface Type PCIe Gen4 NVMe
Drive Interface Lane Count x4
Interface Protocol NVMe 1.3

Compliance & Origin
Country of Origin
TAA Compliant
RoHS Compliance Yes
UL Certification Yes
FCC Certification Yes
CE Mark Yes

Advanced Security Features
Security Type End-to-End Data Protection
Encryption Support AES 256-bit Self-Encrypting Drive (SED)
FIPS 140-2 Compliance Yes (select models)
Secure Erase Yes
