| Processor | Intel, Core i7, 14700, Base 2.1GHz, Smart Cache 33MB, MaxTurbo 5.4GHz |
| RAM | DDR5 UDIMM, Total Installed 16GB, 5600MHz, Max Supported 64GB |
Lenovo ThinkCentre M70s Gen 5 SFF i7-14700 16GB 512GB SSD Win11 Pro
Photo is for illustration purposes only. Actual product may be different.
Regular price
$1,823.69
Regular price
Sale price
$1,823.69
Unit price
per
MSRP: $1,829.00
Shipping calculated at checkout.
Couldn't load pickup availability
- Intel Core i7-14700 processor with 20 cores and up to 5.4GHz turbo frequency
- 16GB DDR5 5600MHz RAM, expandable up to 64GB via two UDIMM slots
- 512GB PCIe Gen4 M.2 SSD for fast, reliable storage
- Integrated Intel UHD Graphics 770 with HDMI and DisplayPort outputs
- Wi-Fi 6 (802.11ax) and Bluetooth 5.3 connectivity
- 3-year on-site warranty and TPM 2.0 security compliance (FIPS 140-2 certified)
Key Benefits
Eye-Insights™ by Eye-In Technologies
AI-Powered Summaries from Online Customer Reviews
AI-Powered Summaries from Online Customer Reviews
Eye-Insights™ are generated by proprietary AI that analyzes real online customer reviews to highlight top pros and key product features. While we aim for accuracy, insights are provided “as-is” and individual results may vary.
- Harness top-tier processing with the 14th Gen Intel Core i7-14700's 20-core performance—ideal for multitasking and productivity.
- Boost performance and future-proof your setup with DDR5 RAM at 5600 MHz and room to upgrade to 64GB.
- Professional-grade security and stability with TPM 2.0, Intel vPro support, and a 3-year on-site warranty included.
Product Overview
The Lenovo ThinkCentre M70s Gen 5 Small Form Factor desktop delivers enterprise-grade performance in a compact footprint. It is powered by an Intel Core i7-14700 CPU with 20 cores and a 5.4 GHz turbo boost, supported by 16GB DDR5 5600MHz RAM. For storage, it includes a 512GB PCIe Gen4 SSD, ensuring fast access and boot times. The system supports dual displays through HDMI and DisplayPort, and integrates Intel UHD Graphics 770. Connectivity includes USB-C with 15W charging, Wi-Fi 6, and Bluetooth 5.3. Security is bolstered with TPM 2.0 (FIPS certified) and Intel vPro support, while an efficient 260W PSU anchors power needs. Preloaded with Windows 11 Pro and backed by a 3-year on-site warranty, it’s a robust choice for modern workspaces.
Specifications
General
Memory
| Cache Memory Type | Smart Cache |
| RAM / Installed Qty | 1 |
| RAM / Total Slots Qty | 2 |
| RAM / Technology | DDR5 |
| RAM / Total Installed Size | 16 GB |
| RAM / Memory Speed | 5600 MHz |
| RAM Form Factor | UDIMM |
| RAM / Max Supported Size | 64 GB |
Storage
| Hard Drive / Type | SSD |
| Hard Drive Capacity / HDD | None GB |
| Hard Drive / Installed Qty | None |
| Hard Drive / Spindle Speed | None RPM |
| SSD Capacity | 512 GB |
| SSD / Installed Qty | 1 |
| Optical Storage Type | DVD+/-RW |
| Storage Controller Type | M.2 |
| Hard Drive / Capacity (2nd) | None GB |
I/O
| Input Device Support Type | Keyboard |
| Keyboard | USB Traditional Keyboard, Black, English |
| Mouse | USB Calliope Mouse, Black |
| Keyboard Language | English |
Power
| Power / Device Type | Power Supply |
| Power / Provided (W) | 260 Watt |
| Efficiency | 90% |
Video
| Graphics Controller | Intel UHD Graphics 770 |
| Video Memory / Technology | None |
| Video Memory / Installed Size | None GB |
| Video Output Interface | Display Port, HDMI |
UNSPSC Code
| UNSPSC Code | 43211508 |
Primary Information
| System Type | Personal Computer |
| Model | ThinkCentre M70s Gen 5 |
| Cabinet Form Factor | Small Form Factor |
| Processor / Generation | Intel 14th Generation |
| Processor / Type | Core i7 |
| Processor / Manufacturer | Intel |
| Multi-Core Technology | 20-Core |
| Processor / Clock Speed | 2.1 GHz |
| Cache Memory Installed Size | 33 MB |
| Max Turbo Frequency | 5.4 GHz |
| Processor / Number | 14700 |
| Processor / Installed Qty | 1 |
| Cache Memory Installed Size | 33 MB |
| RAM / Installed Qty | 1 |
| Mainboard / Chipset Type | Intel Q670 |
| RAM / Technology | DDR5 |
| RAM / Total Slots Qty | 2 |
| RAM / Total Installed Size | 16 GB |
| RAM / Memory Speed | 5600 MHz |
| RAM Form Factor | UDIMM |
| RAM / Max Supported Size | 64 GB |
| Storage Controller Type | M.2 |
| Hard Drive / Type | SSD |
| Hard Drive Capacity / HDD | None GB |
| Hard Drive / Installed Qty | None |
| Hard Drive / Spindle Speed | None RPM |
| SSD Capacity | 512 GB |
| SSD / Installed Qty | 1 |
| Optical Storage Type | DVD+/-RW |
| Audio Output | High Definition (HD) Audio, Realtek ALC623-CG codec |
| Storage Controller Type | M.2 |
| Memory Card Reader | None |
| Hard Drive / Capacity (2nd) | None GB |
| Data Link Protocol | Wi-Fi, Bluetooth |
| Network Controller | Intel Wi-Fi 6E AX211 |
| Graphics Controller | Intel UHD Graphics 770 |
| Video Memory / Technology | None |
| Video Memory / Installed Size | None GB |
| Video Output Interface | Display Port, HDMI |
| Speakers | 1 x 1W |
| Input Device Support Type | Keyboard |
| Keyboard Language | English |
| Keyboard | USB Traditional Keyboard, Black, English |
| Mouse | USB Calliope Mouse, Black |
| Operating System | Microsoft Windows 11 Professional |
| Power / Device Type | Power Supply |
| Power / Provided (W) | 260 Watt |
| Efficiency | 90% |
| Interfaces & Connections | Front Ports: 1x USB-C (USB 5Gbps / USB 3.2 Gen 1), with 15W charging, 4x USB-A (USB 5Gbps / USB 3.2 Gen 1), 1x headphone / microphone combo jack (3.5mm), 1x microphone (3.5mm); Rear Ports: 4x USB-A (Hi-Speed USB / USB 2.0), 1x HDMI 2.1 TMDS, 1x DisplayPort 1.4a (HBR2, DSC), 1x Ethernet (RJ-45) |
| Front I/O Ports | 1x USB-C (USB 5Gbps / USB 3.2 Gen 1), with 15W charging, 4x USB-A (USB 5Gbps / USB 3.2 Gen 1), 1x headphone / microphone combo jack (3.5mm), 1x microphone (3.5mm) |
| Rear I/O Ports | 4x USB-A (Hi-Speed USB / USB 2.0), 1x HDMI 2.1 TMDS, 1x DisplayPort 1.4a (HBR2, DSC), 1x Ethernet (RJ-45) |
| Expansion Slots Total (Free) | One PCIe 3.0 x16, low-profile, length 155mm, height 70mm, One PCIe 3.0 x1, low-profile, length 155mm, height 70mm, Two M.2 slots (one for WLAN, one for SSD) |
| Width | 3.6 Inch |
| Depth | 11.7 Inch |
| Height | 13.4 Inch |
| Weight | 11.7 lbs. |
| Enclosure Color | Black |
| Service & Support Type | 3-year, Onsite Warranty |
| Security Devices | Discrete TPM 2.0, TCG certified, FIPS 140-2 certified |
| Features | Integrated 100/1000M |
| Stand | None |
Processor
| Processor / Generation | Intel 14th Generation |
| Processor / Type | Core i7 |
| Processor / Manufacturer | Intel |
| Multi-Core Technology | 20-Core |
| Processor / Clock Speed | 2.1 GHz |
| Max Turbo Frequency | 5.4 GHz |
| Processor / Number | 14700 |
| Processor / Installed Qty | 1 |
| Cache Memory Type | Smart Cache |
| Cache Memory Installed Size | 33 MB |
Expansion
| Interfaces & Connections | Front Ports: 1x USB-C (USB 5Gbps / USB 3.2 Gen 1), with 15W charging, 4x USB-A (USB 5Gbps / USB 3.2 Gen 1), 1x headphone / microphone combo jack (3.5mm), 1x microphone (3.5mm); Rear Ports: 4x USB-A (Hi-Speed USB / USB 2.0), 1x HDMI 2.1 TMDS, 1x DisplayPort 1.4a (HBR2, DSC), 1x Ethernet (RJ-45) |
| Expansion Slots Total (Free) | One PCIe 3.0 x16, low-profile, length 155mm, height 70mm, One PCIe 3.0 x1, low-profile, length 155mm, height 70mm, Two M.2 slots (one for WLAN, one for SSD) |
| Front I/O Ports | 1x USB-C (USB 5Gbps / USB 3.2 Gen 1), with 15W charging, 4x USB-A (USB 5Gbps / USB 3.2 Gen 1), 1x headphone / microphone combo jack (3.5mm), 1x microphone (3.5mm) |
| Rear I/O Ports | 4x USB-A (Hi-Speed USB / USB 2.0), 1x HDMI 2.1 TMDS, 1x DisplayPort 1.4a (HBR2, DSC), 1x Ethernet (RJ-45) |
Networking
| Data Link Protocol | Wi-Fi, Bluetooth |
| Network Controller | Intel Wi-Fi 6E AX211 |
Special Feature
| Security Devices | Discrete TPM 2.0, TCG certified, FIPS 140-2 certified |
| COO | MEXICO |
| TAA compliance | Yes |
Dimensions&Miscellaneous
| Enclosure Color | Black |
| Width | 3.6 Inch |
| Depth | 11.7 Inch |
| Height | 13.4 Inch |
| Weight | 11.7 lbs. |
