Lenovo ThinkCentre M90a Gen 5 AIO i5, 16GB DDR5, 256GB SSD, MX570A

VENDOR: LENOVO Mfg Part#: 12SH002CUS
1 5
Photo is for illustration purposes only. Actual product may be different.
$1,599.00
$1,599.00
Sale Sold out
Shipping calculated at checkout.
  • 14-core Intel Core i5-14500 processor with up to 5.0GHz turbo frequency
  • 16GB DDR5 RAM with 5600MHz speed for high-performance multitasking
  • 256GB PCIe Gen4 TLC SSD for fast storage and application loads
  • 23.8-inch Full HD display with 99% color gamut and 60Hz refresh rate
  • Discrete NVIDIA GeForce MX570A graphics for enhanced visual performance
  • Integrated Wi-Fi 6, Bluetooth 5.3, and USB-C (10Gbps) connectivity

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Designed for business performance with Intel vPro-enabled Core i5 CPU and DDR5 memory
  • All-in-one form factor reduces workspace clutter while including premium display, camera, and speakers
  • Enterprise-grade security with TPM 2.0, IR hybrid camera, and a 3-year on-site warranty

Product Overview

ThinkCentre M90a Gen 5, Intel Core i5-14500 vPro (E-cores up to 3.70GHz, 24MB), W11P64 ENG, 16.0GB, 1x256GB SSD M.2 2280 PCIe Gen4 TLC Opal, 1xNVIDIA GeForce MX570A 4GB, Slim DVD RAMBO,IntelAX211vPro,BT 5.3, 230W, 3 Year On-site, USB, Calliope, Black-English (US), USB Calliope Mouse (Black)

Specifications

Product Overview
Product Type All-in-One Desktop
Model ThinkCentre M90a Gen 5
Processor Intel Core i5-14500 vPro
Processor Base Clock Speed 2.6 GHz
Max Turbo Frequency 5 GHz
Processor Cores 14-Core
Cache 24 MB Intel Smart Cache
Chipset Intel Q670
Memory Installed 16 GB DDR5
Memory Speed 5600 MHz
Maximum Memory Supported 64 GB
Memory Slots 1 x SODIMM
Storage Type M.2 2280 PCIe Gen4 NVMe SSD
Storage Capacity 256 GB
Optical Drive Slim DVD±RW (RAMBO)
Graphics Card NVIDIA GeForce MX570A 4GB
Operating System Windows 11 Professional 64-bit
Power Supply 230 Watts
Weight 7.83 kg

Wireless Features
Wi-Fi Standard Wi-Fi 6E (802.11ax)
Bluetooth Version Bluetooth 5.3
Wireless Adapter Intel AX211 vPro

Compliance & Origin
Country of Origin Mexico
TAA Compliance Yes
TPM Discrete TPM 2.0, TCG certified, FIPS 140-2 certified

Interfaces
USB Ports 1x USB-C (10 Gbps, USB 3.2 Gen 2, 15W charging)
Video Output Ports DisplayPort, HDMI
Audio Output High Definition Audio
Networking Integrated 100/1000M Ethernet
Expansion Slots Three M.2 slots (one for WLAN, two for SSD)

Physical & Environmental
Display Size 23.8 inch
Display Resolution 1920 x 1080 (Full HD)
Display Refresh Rate 60 Hz
Brightness 250 nits
Aspect Ratio 16:9
Color Gamut 99%
Touchscreen No
Camera 5.0MP + IR Hybrid
Speakers 2 x 3W
Keyboard USB Calliope Keyboard (English, Black)
Mouse USB Calliope Mouse (Black)
Color Black
Stand Included Yes
Dimensions (W x D x H) 21.24 x 13.55 x 8.96 inches

Cloud Management & Licensing
Windows Version Windows 11 Pro 64-bit
Warranty 3 Years On-site
