LG LSAB012-Q12 LED Display, 1.25mm Pixel Pitch, 1600nit Peak Brightness

VENDOR: LG Mfg Part#: LSAB012-Q12 UPC#: 195174044193
1 2
Photo is for illustration purposes only. Actual product may be different.
$6,030.00
$6,030.00
Sale Sold out
MSRP: $8,050.00
Shipping calculated at checkout.
  • LED display with 1.25mm pixel pitch for high-resolution visuals
  • Peak brightness of 1600 nits and typical brightness of 800 nits
  • Utilizes COB (Chip On Board) LED technology for durability and consistency
  • Main top signal redundancy for enhanced operational reliability
  • Compact size: 600 mm width, 337.5 mm height, 44.9 mm depth
  • TAA-compliant and manufactured in South Korea

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Ensures sharp image quality ideal for high-resolution content via 1.25mm pixel pitch
  • Maintains continuous operation with built-in top-level signal redundancy
  • Offers reliable sourcing and compliance for institutional buyers due to TAA certification and Korean manufacturing

Product Overview

1.25mm,Peak. 1,600nit Typ. 800nit,COB,600 x 337.5 x 44.9_Main Top Signal redundancy

Specifications

Product Overview
Product Type Direct View LED Display
Pixel Pitch 1.25 mm
Peak Brightness 1600 nit
Typical Brightness 800 nit
LED Technology Chip-on-Board (COB)
Form Factor Modular Panel
Power Consumption (Max) 225 W per panel
Power Consumption (Avg) 90 W per panel
Power Supply 100–240V AC, 50/60 Hz
Redundancy Main Top Signal Redundancy Supported

Wireless Features

Compliance & Origin
Country of Origin Republic of Korea
TAA Compliant Yes
EMC Certification FCC Class A, CE
Safety Certification ETL, CB, CE
RoHS Compliant Yes
Environment Standard ENERGY STAR Certified (via controller, if applicable)

Advanced Security Features
Secure Access Control Network-based access restriction supported
Data Encryption Supported via Management Software

Interfaces
Signal Input HDMI, DisplayPort via External Controller (LCIN006)
Signal Redundancy Yes (Main, Backup Input Available)
Control Interface LAN (RJ45)
Service Interface USB (via Controller)

Physical & Environmental
Panel Width 600 mm
Panel Height 337.5 mm
Panel Depth 44.9 mm
Panel Weight 7.8 kg
Bezel Width 0.5 mm (Edge-to-Edge)
Operating Temperature 0°C to 40°C
Storage Temperature -20°C to 60°C
Operating Humidity 10% to 80% RH (non-condensing)
Cooling System Fanless / Natural Convection

Cloud Management & Licensing
Remote Management Supported via LG SuperSign / LED Assistant Software
Control Software LG LED Assistant
Web-Based Management Yes, via external controller
Included Software Licenses LED Assistant Basic (Free)
Controller Compatibility Requires LCIN006 or compatible LED controller
