LG LSAB012-T12 COB LED Display, 1.25mm Pixel Pitch, 1600nit Peak Brightness

VENDOR: LG Mfg Part#: LSAB012-T12 UPC#: 195174044216
1 2
Photo is for illustration purposes only. Actual product may be different.
$6,105.00
$6,105.00
Sale Sold out
MSRP: $8,150.00
Shipping calculated at checkout.
  • 1.25mm pixel pitch for fine-resolution LED performance
  • 1600 nit peak and 800 nit typical brightness for high-visibility imaging
  • Secondary signal and power redundancy for fail-safe operations
  • Compact panel size: 600 x 337.5 x 44.9 mm
  • COB (Chip-on-Board) LED technology for enhanced durability and clarity
  • TAA compliant, origin: Republic of Korea

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Highly reliable design featuring dual signal and power redundancy for mission-critical applications
  • Exceptional brightness (up to 1600 nits) ensures clear visuals in indoor high-ambient lighting conditions
  • COB LED technology with fine pixel pitch provides crisp, uniform imagery suitable for professional video walls

Product Overview

1.25mm,Peak. 1,600nit Typ. 800nit,COB,600 x 337.5 x 44.9_Secondary Signal(+Power) redundancy

Specifications

Product Overview
Product Type Direct View LED Display
Technology Chip-on-Board (COB) LED
Pixel Pitch 1.25 mm
Peak Brightness 1600 nit
Typical Brightness 800 nit
Form Factor Modular LED Panel
Power Consumption (Max) 180 W
Power Consumption (Average) 72 W
Power Supply 100-240V AC, 50/60Hz
Redundancy Support Signal + Power Redundancy

Physical & Environmental
Width 600 mm
Height 337.5 mm
Depth 44.9 mm
Unit Weight 5.4 kg
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Operating Humidity 10% to 90% RH (non-condensing)
Cooling Type Fanless (Natural Convection)
Front Protection IP50
Rear Protection IP20

Cloud Management & Licensing
Remote Management LG ConnectedCare (Optional)
Control Software LG SuperSign CMS, LED Assistant Software
Cloud Compatibility LG ConnectedCare Cloud
Licensing Requirements May require license for ConnectedCare features

Interfaces
Video Input Interface LG CVCA (Control and Video Cable Assembly)
Control Interface Ethernet (RJ45)
Connector Type Proprietary Connectors for LG Controller
Signal Redundancy Supported
Power Redundancy Supported

Compliance & Origin
Country of Origin South Korea
TAA Compliance Yes
Certifications CE, FCC Class A, ETL
EMC Standards EN55032 / EN55035
RoHS Compliance Yes

Advanced Security Features
Security Features Encrypted Communication (when used with LG controller)
Access Control Password-protected control interface
