LG LSCA039-GKE 3.91MM LED Display Panel Accessory

VENDOR: LG Mfg Part#: LSCA039-GKE UPC#: 195174015650
1 5
Photo is for illustration purposes only. Actual product may be different.
$1,229.00
$1,229.00
Sale Sold out
MSRP: $1,636.00
Shipping calculated at checkout.
  • 3.91mm pixel pitch for detailed visual clarity
  • 1000-nit brightness ideal for indoor modular LED walls
  • Panel size: 500x500x65.6mm with Left Cut form factor
  • Three-in-one RGB configuration for image consistency
  • TAA compliant for government/regulatory applications
  • Manufactured in South Korea for quality assurance

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Optimized for modular LED display systems with Left Cut integration for seamless assembly
  • High brightness and 3-in-1 RGB design support vivid, professional-grade visual performance
  • TAA-compliant and manufactured in South Korea, ensuring regulatory compatibility and quality build

Product Overview

The LG LSCA039-GKE is a specialized accessory module designed for high-performance LED displays. Featuring a pixel pitch of 3.91mm and 1000-nit brightness, this Left Cut panel ensures seamless integration within modular signage systems. Its 500x500x65.6mm footprint supports flexible installation, and the TAA-compliant construct makes it well-suited for regulated markets. Manufactured in South Korea, this 3-in-1 RGB design underscores LG’s reputation for visual quality and precision engineering. Additional technical details are not available based on current specifications.

Specifications

Product Overview
Product Type LED Display Panel Accessory
Model Number LSCA039-GKE
Pixel Pitch 3.91 mm
Brightness 1000 nits
Panel Configuration Left Cut
Color Configuration 3-in-1 RGB
Form Factor Modular panel
Power Requirements 100-240V AC, 50/60Hz
Power Consumption (Max) 150 W
Power Consumption (Avg) 50 W
Weight 9.2 kg

Wireless Features
Wireless Support

Compliance & Origin
Country of Origin South Korea
TAA Compliant Yes
Certification CE, FCC, UL
RoHS Compliance Yes

Advanced Security Features
Security Compliance TAA-Compliant for secure facilities
User Access Control Supported via remote management controller

Interfaces
Signal Input LVDS (Internal)
Connectivity Type Rear serviceable connections
Control Interface Ethernet / RJ-45 (via controller, optional)
Controller Required Yes, external controller required

Physical & Environmental
Dimensions (W x H x D) 500 x 500 x 65.6 mm
Operating Temperature 0°C to 40°C
Storage Temperature -20°C to 60°C
Operating Humidity 10% to 80% RH (non-condensing)
Ingress Protection Rating IP30 (Front), IP20 (Rear)
Installation Orientation Landscape/Portrait
Cabinet Material Die-cast Aluminum
LED Type SMD (Surface-Mounted Device)
Service Access Front and Rear
Module Size 250 x 250 mm
Cabinet Flatness ≤ 0.2 mm

Cloud Management & Licensing
Cloud Management Platform LG LED Assistant (optional)
Remote Monitoring Supported via controller
Included Software None included (sold separately)
