LG MAGNIT LSAP012-T22 DVLED Panel, 480x270, Signal+Power Redundancy

VENDOR: LG Mfg Part#: LSAP012-T22 UPC#: 195174090770
1 4
Photo is for illustration purposes only. Actual product may be different.
$6,977.00
$6,977.00
Sale Sold out
MSRP: $8,722.00
Shipping calculated at checkout.
  • 480 x 270 display resolution
  • Signal and power redundancy for increased system reliability
  • Fused COB (Chip-On-Board) construction for durability and thermal efficiency
  • Secure DP Docking Panel/Cabinet for stable modular installation
  • Physical dimensions: 600x337.5x44.9 mm
  • TAA compliant and manufactured in South Korea

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Redundant signal and power design ensures higher system uptime in demanding environments.
  • TAA compliance and Korean manufacturing support secure procurement for government or institutional use.
  • Fused COB and Secure Docking architecture offer long-term reliability and simplified maintenance.

Product Overview

MAGNIT LSAP Series DVLED, 0, 480x270 resolution, Signal+Power Redundancy, Secondary, Secure DP Docking Panel/Cabinet Premium others class, Fused COB, 0 nit, 600x337.5x44.9

Specifications

Product Overview
Product Type Direct View LED (DVLED) Display Panel
Series MAGNIT LSAP
Model Number LSAP012-T22
Form Factor Cabinet Panel
Pixel Pitch 1.25 mm
Display Technology Fused Chip on Board (COB) LED
Display Resolution 480 x 270
Brightness (Typical) 600 nits
Cabinet Material Die-Cast Aluminum
Power Redundancy Yes
Signal Redundancy Yes
Power Consumption (Max) 165 W
Power Consumption (Average) 55 W
Input Voltage 100–240V AC, 50/60Hz
Weight per Cabinet 7.2 kg

Wireless Features
Wireless Capability

Compliance & Origin
Country of Origin South Korea
TAA Compliant Yes
RoHS Compliant Yes
EMC Certification FCC Class A / CE / KC
Safety Certification CB / ETL

Advanced Security Features
Secure Docking Interface Yes
Tamper-Resistant Design Yes

Interfaces
Input Signal Interface Secure DP Docking Connector
Signal Input DisplayPort via Docking Interface
Control Interface RS232C / RJ45
Module-to-Module Connector Dedicated PIN Type

Physical & Environmental
Cabinet Dimensions (W x H x D) 600 x 337.5 x 44.9 mm
Operating Temperature Range 0°C to 40°C
Storage Temperature Range -20°C to 60°C
Operating Humidity Range 10% to 80% RH (non-condensing)
Storage Humidity Range 10% to 85% RH (non-condensing)
Ingress Protection (Front) IP5X
Cooling System Fanless

Cloud Management & Licensing
Remote Management Support LG ConnectedCare (Optional)
Management Interface LAN Control via RJ45
Software Compatibility LG LED Assistant, SuperSign CMS
