PLANAR PCT2235 22" PCAP Touchscreen IPS Monitor with Helium Stand, Black

VENDOR: PLANAR Mfg Part#: 997-8286-00 UPC#: 810689003120
1 5
Photo is for illustration purposes only. Actual product may be different.
$306.11
$306.11
Sale Sold out
MSRP: $315.00
Shipping calculated at checkout.
  • 21.5" Full HD (1920 x 1080) IPS LED-backlit display with 178° viewing angle
  • Projected capacitive 10-point multi-touch support for responsive input
  • Integrated VGA, HDMI, DisplayPort, and USB inputs for flexible connectivity
  • Helium stand with +15° to +70° tilt and flat orientation support
  • VESA 100 x 100 mm compatible and includes two 2W integrated speakers
  • Three-year Customer First Warranty with free advance replacement in the U.S.

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Versatile Helium stand provides flexible ergonomics and usability in various environments, including flat tabletop use.
  • Multi-interface design (HDMI, VGA, DisplayPort) ensures compatibility with legacy and modern systems, reducing the need for adapters.
  • Comprehensive warranty with free advance replacement enhances ROI by minimizing downtime during support needs.

Product Overview

22Inch wide black projected capacitive multi-touch IPS edge-lit LED LCD, USB controller, VGA, HDMI, DP, speakers, and Helium Stand supporting 15 to 70 tilt range and flat orientation.

Specifications

Product Overview
Product Type Touchscreen Monitor
Form Factor Desktop
Display Size 21.5 Inch
Display Technology IPS Edge-lit LED
Flat / Curved Flat
Weight 3.6 kg
Power Requirements 100-240 VAC, 50/60 Hz
Power Consumption (Operational) 27 Watt
Power Consumption (Standby) <0.5W

Display Features
Native Resolution 1920 x 1080
Aspect Ratio 16:9
Color Support 16.7 Million Colors
Contrast Ratio 1000:1
Brightness (With Touchscreen) 212 cd/m²
Brightness (Without Touchscreen) 250 cd/m²
Viewing Angle (H/V) 178° / 178°
Response Time 14 ms
Refresh Rate 60 Hz
Pixel Pitch 0.24825 mm

Physical & Environmental
Dimensions (W x H x D) 19.3 in x 11.8 in x 1.9 in
Tilt Adjustment +15° to +70°, fold-flat orientation
Mounting Option VESA 100 x 100 mm
Operating Temperature Range 0°C to 40°C
Operating Humidity Range 10% - 90% RH (non-condensing)
Color Black

Cloud Management & Licensing
Cloud Management
Licensing Requirements None

Interfaces
Video Inputs VGA, HDMI, DisplayPort
Audio Input 3.5 mm audio jack
USB Connectivity USB A to B (touch interface)
AC Power Input Yes
Speakers 2 x 2W integrated speakers

Touchscreen Features
Touchscreen Technology Projected Capacitive (PCAP)
Multi-Touch Support Yes
Operating System Compatibility HID Compliant (Windows)

Compliance & Origin
Country of Origin China
RoHS Compliant Yes
TAA Compliant No
Certification Standards CE, FCC, ENERGY STAR, RoHS

Advanced Security Features
Hardware Security
Kensington Lock Slot Yes
