PLANAR PCT2495 Helium 24in FHD Touchscreen Monitor, Zero Bezel, USB Hub

VENDOR: PLANAR Mfg Part#: 998-3328-00 UPC#: 810069810775
  • PLANAR PCT2495 Helium 24in touchscreen monitor, black, zero bezel, HID cmpl, optically bonded PCAP multi-touch FHD IPS LED LCD, HDMI DP USB3.0 Hub
1 1
Photo is for illustration purposes only. Actual product may be different.
$403.40
$403.40
Sale Sold out
MSRP: $416.00
Shipping calculated at checkout.
  • 23.8" Full HD (1920 x 1080) IPS touch display with 178° wide viewing angles
  • Projected capacitive (PCAP) optically bonded multi-touch screen
  • Zero bezel design for seamless edge-to-edge interaction
  • Connectivity options include HDMI, DisplayPort, USB (A to B), and 3.5mm audio output
  • Integrated speakers and USB 3.0 hub built-in
  • Adjustable tilt from 15° to 65° and VESA 100x100 mm mount support
View full details

Key Benefits

Eye-Insights
  • Delivers high interactivity and durability with optically bonded PCAP multi-touch technology
  • Multiple connectivity ports including HDMI, DisplayPort, and USB simplify system integration in diverse workflows
  • Backed by a 3-Year Customer First Warranty, ensuring long-term ROI and reduced total cost of ownership

Product Overview

HELIUM 24Inch WIDE BLACK ZERO BEZEL, HID COMPLIANT OPTICALLY BONDED PROJECTED CAPACITIVE MULTI-TOUCH FHD IPS EDGE-LIT LED LCD, HDMI, DP, USB3.0 HUB,

Specifications

Primary Information
Model PCT2495
Display Type LCD Display
Display Format FHD
Display Technology IPS
Flat / Curved Flat
Max Resolution 1920 x 1080
Display Diagonal Size 23.8 Inch
Display / Color Support 16.7 Million Colors
Display / Response Time 5 Ms
Display / Refresh Rate 60 Hz
Dot Pitch / Pixel Pitch 0.2745 Mm
Image Contrast Ratio 1000:1
Brightness 360 nits
Viewing Angle 178/178
Image Aspect Ratio 16:9
Screen Type Anti-glare
HDR Capable None
Audio Output Headphone Out
Speakers Yes
Interfaces HDMI 19-pin, DisplayPort 20-pin, 3.5mm headphone out, USB (A to B), USB 3.0 A type x 2, AC power-in
Video Interfaces HDMI; DisplayPort
Power Consumption Operational 35 Watt
Power Consumption (Off Mode) <1w
Power / Voltage Required 100-240 VAC, 50/60 Hz
Power Consumption Standby <1w
Adjustable Display Tilt 15 to 65 degree
VESA Mount Compatible 100 x 100 mm
Width 22.3 Inch
Depth 1.7 Inch
Height 13.3 Inch
Weight 9.7 lbs.
Service & Support Type 3-Year Customer First Warranty
What's Included PCT2495 24 inch Wide Multi-Touch Monitor, Power Cord, HDMI Cable, DP Cable, USB Cable (A to B), User's Guide, Cleaning Cloth, Cable Wrap
Min Operating Temperature 0 Celsius
Max Operating Temperature 40 Celsius
Humidity Range Operating 10 - 90% RH

UNSPSC Code
UNSPSC Code 43211902

Power
Power / Voltage Required 100-240 VAC, 50/60 Hz
Power Consumption Operational 35 Watt
Power Consumption (Off Mode) <1w

Special Feature
COO CHINA
RoHS Y
Adjustable Display Tilt 15 to 65 degree

Display
Brightness 360 nits
Display / Color Support 16.7 Million Colors
Display Diagonal Size 23.8 Inch
Display Type LCD Display
Dot Pitch / Pixel Pitch 0.2745 Mm
Flat / Curved Flat
HDR Capable None
Image Aspect Ratio 16:9
Screen Type Anti-glare
