PLANAR PT1545P 15in Touchscreen POS Monitor, PCAP, XGA, HDMI/VGA/DP

VENDOR: PLANAR Mfg Part#: 997-7413-01 UPC#: 810689009801
1 2
Photo is for illustration purposes only. Actual product may be different.
$500.11
$500.11
Sale Sold out
MSRP: $506.00
Shipping calculated at checkout.
  • 15-inch LED LCD screen with XGA resolution provides clear, detailed visuals
  • Projected capacitive (PCAP) touchscreen supports multi-touch input and HID compliance
  • Connectivity via VGA, HDMI, and DisplayPort for flexible system integration
  • Built-in speakers eliminate the need for external audio devices
  • 90-degree tilt enables ergonomic positioning for user comfort
  • Constructed in black chassis; made in China; not TAA compliant

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Ideal for interactive POS environments requiring responsive multi-touch input
  • Versatile connectivity ensures compatibility with various hardware setups
  • Integrated speakers and tilting design improve usability and reduce peripheral costs

Product Overview

15Inch black point of sale monitor, HID compliant projected capacitive multi-touch XGA LED LCD, VGA, HDMI, DP inputs, speakers, 90 degree tilt.

Specifications

Product Overview
Product Type Touchscreen POS Monitor
Model Name PLANAR PT1545P
Manufacturer Part Number 997-7413-01
Form Factor Desktop
Color Black
Touch Technology Projected Capacitive (PCAP)
Touch Points 10-point Multi-touch
Display Diagonal Size 15 Inch
Display Resolution 1024 x 768 (XGA)
Display Type LED-backlit LCD
Backlight Technology LED
Aspect Ratio 4:3
Response Time 8 ms
Contrast Ratio 700:1
Brightness 250 cd/m²
Viewable Image Area 304.1 mm x 228.1 mm
Viewing Angle 140° horizontal / 120° vertical
Horizontal Frequency 30 kHz – 82 kHz
Vertical Frequency 50 Hz – 75 Hz
Power Consumption (Operational) 18 Watts (typical)
Power Consumption (Standby) <0.5 Watts
Power Supply External, 12V DC
Speakers Yes, integrated

Physical & Environmental
Tilt Angle 0° to 90°
Mounting Options 100 x 100 mm VESA Mount Compatible
Dimensions (W x H x D) 354.5 x 319.3 x 202.0 mm (with stand)
Weight 3.6 kg (7.9 lbs)
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Operating Humidity 10% – 90% RH (non-condensing)

Cloud Management & Licensing
Remote Management

Interfaces
Video Inputs VGA, HDMI, DisplayPort
Touch Interface USB 2.0 (for touch)
Audio Input 3.5mm stereo jack
Number of USB Ports 1 (upstream for touch)

Compliance & Origin
Country of Origin China
RoHS Compliant Yes
ENERGY STAR Certified Yes
TAA Compliant No
Certifications CE, FCC Class B, UL, cUL
UPC 810689009801

Advanced Security Features
Kensington Lock Slot Yes
