PLANAR PT1945P 19in Touchscreen POS Monitor, SXGA, PCAP, Speakers

VENDOR: PLANAR Mfg Part#: 997-7415-01 UPC#: 810689009832
1 5
Photo is for illustration purposes only. Actual product may be different.
$613.18
$613.18
Sale Sold out
MSRP: $631.00
Shipping calculated at checkout.
  • 19-inch flat LED-backlit LCD with 1280 x 1024 SXGA resolution and PCAP multi-touch
  • Supports HDMI, DisplayPort, and VGA inputs for flexible connectivity
  • Integrated 2x 1W speakers for built-in audio output
  • Tilt adjustable from -5° to +90° and VESA 100 x 100 mm mount compatible
  • Low power consumption: 16.1W operational, 0.3W in off mode
  • Wide operating temperature range from 0°C to 40°C with RoHS compliance

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Ideal for POS and kiosk applications with projected capacitive touch and 10-point multi-touch capability
  • Multiple input options (HDMI, DisplayPort, VGA) support both legacy and modern systems
  • Backed by a 3-Year Customer First Warranty, ensuring long-term performance and peace of mind

Product Overview

19Inch black point of sale monitor, HID compliant projected capacitive multi-touch SXGA LED LCD, VGA, HDMI, DP inputs, speakers, 90 degree tilt

Specifications

Product Overview
Product Type Touchscreen POS Monitor
Model PT1945P
Form Factor Desktop
Screen Size 19 Inch
Display Type LED-backlit LCD
Display Technology Edge LED BLU
Resolution 1280 x 1024 (SXGA)
Aspect Ratio 5:4
Contrast Ratio 1000:1
Brightness 212 cd/m²
Color Support 16.7 Million Colors
Pixel Pitch 0.2928 mm
Response Time 5 ms
Refresh Rate 75 Hz
Viewable Angle (H/V) 170° / 160°
Touch Technology Projected Capacitive (PCAP)
Multi-touch Capability Yes
HID Compliant Yes
Speakers Yes
Audio Output 2 x 1W speakers
Power Consumption (Typical) 16.1 W
Power Consumption (Standby) 1.5 W
Power Consumption (Off) 0.3 W
Power Input 100-240 VAC, 50/60 Hz
Tilt Adjustment -5 to +90 degrees
VESA Mounting Support 100 x 100 mm
Includes Stand Yes
Weight 15.2 lbs

Wireless Features

Compliance & Origin
Country of Origin China
RoHS Compliant Yes
TAA Compliant No

Advanced Security Features

Interfaces
Video Inputs HDMI, DisplayPort, VGA

Physical & Environmental
Width 17 Inch
Height 15.4 Inch
Depth 8.6 Inch
Operating Temperature (Min) 0 °C
Operating Temperature (Max) 40 °C
