PLANAR UC Complete 198in 32:9 Video Wall P1.2 with Controller & Mount

VENDOR: PLANAR Mfg Part#: 998-2951-00
1 4
Photo is for illustration purposes only. Actual product may be different.
$92,110.65
$92,110.65
Sale Sold out
MSRP: $92,875.00
Shipping calculated at checkout.
  • 198-inch diagonal video wall with ultra-wide 32:9 aspect ratio
  • High-resolution display at 3840 x 1080, optimized for panoramic content
  • P1.2 pixel pitch for superior image sharpness
  • Includes display controller, wall mount, cables, and spare parts
  • Country of origin: Slovakia
  • TAA-compliant for government and federal deployments

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • All-in-one bundle simplifies deployment with included controller, mount, cables, and spares
  • Meets TAA compliance for eligibility in regulated and government environments
  • Ultra-wide 32:9 ratio and fine pixel pitch provide immersive viewing with high clarity

Product Overview

PLANAR UC COMPLETE, 32-9 RATIO, 198IN DIAGONAL VIDEO WALL (3840 X 1080, P1.2), CONTROLLER, WALL MOUNT, CABLES AND SPARES

Specifications

Product Overview
Product Type All-in-One LED Video Wall Solution
Screen Size (Diagonal) 198 inches
Aspect Ratio 32:9
Native Resolution 3840 x 1080
Pixel Pitch 1.2 mm
Viewing Angle (Horizontal/Vertical) 160° / 160°
Brightness 600 nits typical
Power Consumption (Max) 5,000 W
Power Consumption (Typical) 1,500 W
Power Supply 100-240V AC, 50/60 Hz
Mount Type Wall Mount
Included Controller Video Controller Included
Included Accessories Wall mount, cables, spare parts

Physical & Environmental
Dimensions (W x H x D) 179.7 in x 25.5 in x 3.1 in
Total Display Area Approximately 15.4 ft x 2.1 ft
Unit Weight Approx. 800 lbs (including structure and display)
Operating Temperature 0°C to 40°C
Storage Temperature -20°C to 60°C
Operating Humidity 10% to 80% (non-condensing)
Storage Humidity 10% to 85% (non-condensing)
Cooling Type Active cooling (fans)
Service Access Front serviceable LED modules

Cloud Management & Licensing
Remote Management Yes, via LAN-based controller
Included Software Content management and configuration tool
Cloud Connectivity Optional with compatible platforms
Licensing Requirements None (all components included)

Interfaces
HDMI Inputs 2 x HDMI 2.0
DisplayPort Inputs 1 x DisplayPort 1.2
USB Ports 2 x USB (for service)
Control Interfaces 1 x Ethernet (RJ45), Serial RS232
Audio Output 1 x 3.5 mm

Compliance & Origin
Country of Origin Slovakia
TAA Compliant Yes
RoHS Compliant Yes
Certifications FCC Class A, CE, UL, TUV

Advanced Security Features
Secure Access Control Password-protected access to controller settings
Network Segmentation Supported via LAN configuration
