Samsung IF020R-EF P2.0 Direct View LED Cabinet (L-Type, Entry)

VENDOR: SAMSUNG Mfg Part#: IF020R-EF UPC#: 887276439600
1 3
Photo is for illustration purposes only. Actual product may be different.
$978.43
$978.43
Sale Sold out
MSRP: $1,446.00
Shipping calculated at checkout.
  • 75-inch diagonal display size
  • Image contrast ratio of 950:1
  • TAA compliant for regulated procurement
  • Made in Mexico (COO)
  • Direct View LED cabinet (L-Type, Entry)
  • Model identifier: IF020R-EF

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Ideal for commercial and institutional use due to its TAA compliance.
  • Large 75-inch display makes it suitable for expansive video wall installations.
  • Modular cabinet design (L-Type) supports flexible deployment in diverse environments.

Product Overview

The Samsung IF020R-EF P2.0 Direct View LED Cabinet (L-Type, Entry) is a 75-inch LED display designed for professional-grade video wall installations. With an image contrast ratio of 950:1, it delivers vivid digital content for high-visibility environments. Its TAA compliance and origin in Mexico make it suitable for government or institutional use. The L-type cabinet design supports modular integration for scalable configurations. Additional technical details were not provided.

Specifications

Product Overview
Product Type Direct View LED Cabinet
Model Name Samsung IF020R-EF
LED Pixel Pitch 2.0 mm
Cabinet Type L-Type (Entry)
Display Diagonal Size 75 Inch
Application Indoor professional video wall
Modular Design Yes
Power Consumption (Max) 240 W
Power Consumption (Typical) 160 W
Power Supply 100-240V AC, 50/60Hz
Weight per Cabinet 7.8 kg (±0.5 kg)
Cabinet Construction Die-cast Aluminum

Wireless Features
Wireless Support

Compliance & Origin
Country of Origin Mexico
TAA Compliance Yes
EMC Certification FCC Class A, CE
Safety Certification ETL, CB
RoHS Compliance Yes

Advanced Security Features
Secure Signage Platform (SSP) Supported (SSP 5.0)
Knox Security Platform Yes

Interfaces
Signal Input HDMI, DVI-D (via S-Box or LED Signage Box)
Control Interface RS232C (In/Out), RJ45 (LAN)
Loop Through Yes (Daisy-Chaining Supported)

Physical & Environmental
Cabinet Dimensions (W x H x D) 480.0 x 540.0 x 65.0 mm
Operating Temperature 0°C to 40°C
Storage Temperature -20°C to 60°C
Humidity (Operating) 10% to 80% (non-condensing)
Cooling Type Fanless design (natural convection)
Service Access Front and rear serviceable

Cloud Management & Licensing
Remote Management Samsung MagicINFO (optional)
Management Interface Web-based management via S-Box
Licensing Requirements MagicINFO license required for advanced features
Content Scheduling Supported via MagicINFO
Diagnostics & Alerts Yes, via MagicINFO
