Samsung XHB-SP6FLAT1X3 Outdoor LED Display Panel

VENDOR: SAMSUNG Mfg Part#: LH060XHBTIS UPC#: 8806094567311
1 1
Photo is for illustration purposes only. Actual product may be different.
$1,710.41
$1,710.41
Sale Sold out
MSRP: $2,283.83
Shipping calculated at checkout.
  • LED display panel with 8000 nits brightness and high 8000:1 contrast ratio
  • Supports 281 trillion colors with 7680 Hz refresh rate for smooth image rendering
  • Pixel pitch of 6.16 mm ensures sharp visual output
  • Wide 160°/130° viewing angle for maximum audience visibility
  • Operational temperature range from -40°C to 55°C for extreme environments
  • Universal 100–240 VAC power input with 95-watt power draw

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Engineered for outdoor use, the panel performs reliably in temperatures ranging from -40°C to 55°C
  • Exceptional brightness (8000 nits) and color depth make it ideal for high-visibility digital signage applications
  • Low power consumption and global voltage compatibility reduce installation and operating complexity

Product Overview

The Samsung XHB-SP6FLAT1X3, model LH060XHBTIS, belongs to the XHB Series of high-performance outdoor LED displays. It offers 8000 nits of brightness and a pixel pitch of 6.16 mm to ensure brilliant, sharp visuals in any lighting condition. With 281 trillion color support and an ultra-smooth 7680 Hz refresh rate, this display provides dynamic, true-to-life images. The unit is engineered for harsh environments, handling temperatures from -40°C to 55°C, and includes broad voltage compatibility for flexible installation. Though HDR and picture enhancements are absent, the panel excels at delivering high-impact content with minimal power usage. Ideal for public venues, commercial signage, and outdoor promotions, it’s a durable, weather-resistant solution for mission-critical messaging.

Specifications

Product Overview
Manufacturer Samsung
Model LH060XHBTIS
Product Type Outdoor LED Display Panel
Series XHB Series
Form Factor Flat Panel
Weight 15.9 kg
Power Consumption (Operational) 95 Watt
Power Requirements 100-240 VAC, 50/60 Hz
Brightness 8000 nits
Refresh Rate 7680 Hz
Image Contrast Ratio 8000:1
Color Support 281 Trillion
Pixel Pitch 6.16 mm
Maximum Resolution 56 x 168

Wireless Features
Wireless Connectivity

Compliance & Origin
Country of Origin Mexico
TAA Compliance Yes
RoHS Compliance Yes
EMC Certification Class A
Regulatory Approvals CE, UL, FCC

Advanced Security Features
Content Protection MagicINFO server content protection features (with license)
Secure Playback Yes, via MagicINFO secure communication

Interfaces
Input Signal Interface Modular, dependent on controller configuration
Controller Type External LED Controller (sold separately)
Signal Type Digital

Physical & Environmental
Width 344.6 mm
Height 1035.4 mm
Depth 91.3 mm
Operating Temperature (Min) -40°C
Operating Temperature (Max) 55°C
Humidity Tolerance 10% to 90% (non-condensing)
Viewing Angle (Horizontal/Vertical) 160° / 130°
Ingress Protection Rating IP66 (Front), IP66 (Rear)
Cooling Method Fanless convection
Mount Type Wall or structure-mounted (using external brackets)

Cloud Management & Licensing
Management Platform Samsung MagicINFO (Optional)
Cloud Connectivity Optional with MagicINFO Server/Cloud
License Requirements MagicINFO license sold separately
Remote Monitoring Yes, via MagicINFO platform
Scheduling Capabilities Yes, via MagicINFO
