Samsung XPR-B 10mm Outdoor LED Display Single Face

VENDOR: SAMSUNG Mfg Part#: LHX10VTB6C0 UPC#: 887276580418
1 2
Photo is for illustration purposes only. Actual product may be different.
$20,935.93
$20,935.93
Sale Sold out
MSRP: $27,997.59
Shipping calculated at checkout.
  • LED Display for outdoor applications
  • Resolution of 288x144 pixels
  • Large 6ft x 12ft format for visibility at a distance
  • TAA-compliant for government and enterprise procurement
  • Made in Mexico for regional sourcing benefits

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Ideal for outdoor advertising and public information due to large format and 10mm pitch
  • Meeting TAA compliance supports use in government-funded projects
  • Reliable manufacturer with a reputation for durable digital signage solutions

Product Overview

The Samsung XPR-B 10mm Outdoor LED Single Face display offers a robust outdoor signage solution designed for visibility and endurance. With a 288x144 resolution and a size of 6 feet by 12 feet, it is ideal for wide-view applications such as public information or commercial advertising. This TAA-compliant unit is manufactured in Mexico, meeting federal acquisition standards. While some technical specifics like response time and diagonal inch size are missing, its designation as a large-format LED display ensures suitability for outdoor installations where size and brightness are key factors.

Specifications

Product Overview
Type Outdoor LED Display
Model Samsung XPR-B 10mm Outdoor LED Display Single Face
Manufacturer Samsung
Manufacturer Part Number LHX10VTB6C0
Display Technology LED
Pixel Pitch 10 mm
Configuration Single Face
Resolution 288 x 144
Aspect Ratio 2:1
Display Size (W x H) 12 ft x 6 ft
Diagonal Size Approximately 13.4 ft
Form Factor Modular Outdoor Cabinet
Typical Power Consumption 787 W/m²
Max Power Consumption 2360 W/m²
Power Supply AC 100–240V, 50/60Hz
Brightness 9,000 nits

Wireless Features
Wireless Connectivity

Compliance & Origin
TAA Compliant Yes
Country of Origin Mexico
Certifications FCC, CE, ETL
RoHS Compliant Yes

Advanced Security Features
Network Security Supports secure access via management platform
Access Control Role-based access (via management software)

Interfaces
Video Input HDMI, DVI, DisplayPort via LED Controller
Data Input Ethernet (CAT5e/CAT6) from Controller
Control Interface RJ45
Diagnostics Interface USB (via controller)

Physical & Environmental
Cabinet Dimensions (W x H x D) 960 mm x 960 mm x 115 mm
Cabinet Material Aluminum Die-Casting
Ingress Protection Rating IP65 front / IP54 rear
Operating Temperature -30°C to +50°C
Operating Humidity 10% ~ 95% (non-condensing)
Storage Temperature -40°C to +60°C
Environment Outdoor Use
Weight per Cabinet 28.5 kg (approx.)

Cloud Management & Licensing
Cloud Management Samsung MagicINFO (optional)
Remote Monitoring Support Yes, via MagicINFO or SNMP
Content Scheduling Supported via MagicINFO
Software Licensing Separate licenses required for MagicINFO
