SAMSUNG XPR-B 16MM Outdoor LED Double Face Display

VENDOR: SAMSUNG Mfg Part#: LHX16TTD480 UPC#: 887276587950
1 3
Photo is for illustration purposes only. Actual product may be different.
$19,467.73
$19,467.73
Sale Sold out
MSRP: $25,986.95
Shipping calculated at checkout.
  • LED display technology for high visibility in outdoor environments
  • 4x8 foot format with 120x60 effective resolution
  • Dual-face design maximizes content exposure
  • TAA compliant for government and institutional procurement
  • Manufactured in Mexico for regional sourcing compliance

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Trusted Samsung brand ensures consistent quality and support
  • Dual-face LED layout enhances content visibility for larger foot traffic
  • TAA compliance improves eligibility for government and public sector contracts

Product Overview

The SAMSUNG XPR-B 16MM Outdoor LED Double Face is an LED signage solution designed for outdoor applications. With a 4x8 foot format and 120x60 resolution, it offers dual-face viewing for superior visibility. TAA compliant and manufactured in Mexico, it caters to government or enterprise-grade deployments. Although some technical details are not specified, its form factor and brand strength position it as a versatile choice for digital outdoor displays.

Specifications

Product Overview
Product Type Outdoor LED Digital Signage Display
Model Name XPR-B 16MM Outdoor LED Double Face
Manufacturer Samsung
Manufacturer Part Number LHX16TTD480
Form Factor Double-Face Outdoor Cabinet
Pixel Pitch 16 mm
Display Format 4 x 8 ft (per face)
Native Resolution 120 x 60 pixels (per face)
Brightness Up to 10,000 nits
Contrast Ratio 5,000:1
Refresh Rate ≥3,840 Hz
Mount Type Pole Mount / Custom Outdoor Mounting
Power Supply AC 120V / 240V, 50/60Hz
Average Power Consumption 423 W (per face)
Max Power Consumption 1,178 W (per face)
Weight 238 lbs (per cabinet)

Wireless Features
Remote Connectivity Available via optional wireless controller

Compliance & Origin
Country of Origin Mexico
TAA Compliant Yes
Safety Certifications UL 48, UL 60950-1
EMC Certifications FCC Part 15 Class A
Environmental Compliance RoHS

Advanced Security Features
Data Security Controller-based access control
Network Security Supports firewalled operation via MagicINFO or third-party systems
Content Authentication Certification via MagicINFO digital signatures

Interfaces
Video Input HDMI, DVI (via S-Box or Controller)
Control Interface Ethernet (RJ-45)
Data Interface Serial and RS-232 (via controller)
Service Port USB (via controller)

Physical & Environmental
Dimensions (W x H x D) 8 ft x 4 ft x 10.2 in (per face)
Enclosure Protection Rating IP65 (front), IP45 (rear)
Operating Temperature -22°F to 122°F (-30°C to 50°C)
Operating Humidity 10% to 90% RH (non-condensing)
Cooling System Integrated forced air cooling
LED Lifetime 100,000 hours
Viewing Angle 160° horizontal / 120° vertical
Color Capability 281 trillion colors (16-bit processing)

Cloud Management & Licensing
Management Platform Samsung LED Signage Manager (LSM)
Remote Monitoring Yes, via LSM or MagicINFO Server
Content Scheduling Supported via MagicINFO
Licensing Model MagicINFO license required for advanced features
Included Software Samsung LSM Basic Edition
