SAMSUNG XPR-B 16MM Outdoor LED Single Face Display 3Hx8W

VENDOR: SAMSUNG Mfg Part#: LHX16TTB380 UPC#: 887276580425
1 3
Photo is for illustration purposes only. Actual product may be different.
$9,790.30
$9,790.30
Sale Sold out
MSRP: $13,087.31
Shipping calculated at checkout.
  • 16mm pixel pitch LED display for effective outdoor signage
  • 3Hx8W enclosure configuration with 120x45 resolution
  • Manufactured in Mexico; TAA compliant for government use
  • Classified as Digital Signage Display > 45 inch
  • LED technology offers brightness and low power consumption

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Commercial-grade LED construction ensures high visibility in outdoor light conditions.
  • TAA compliance makes the unit ideal for federal and institutional procurement.
  • Samsung branding with origin in Mexico supports global product support and manufacturing standards.

Product Overview

The SAMSUNG XPR-B 16MM Outdoor LED Single Face Display is engineered for impactful outdoor messaging, designed for use in digital signage applications requiring strong visibility and durability. This display features a 16mm pixel pitch and a 3Hx8W cabinet configuration, accommodating a 120x45 resolution in a single-face layout. Manufactured in Mexico and TAA-compliant, it is optimized for government and institutional procurement. Its LED-based technology offers high brightness levels and energy efficiency, making it suitable for demanding, outdoor public display environments.

Specifications

Product Overview
Product Type Outdoor LED Digital Signage Display
Cabinet Configuration 3Hx8W
Pixel Pitch 16 mm
Display Resolution 120 x 45 pixels
Face Configuration Single Face
Display Technology Direct-View LED
Mount Type Custom Outdoor Mounting System
Brightness Up to 7,000 nits
Color Capability Full Color (RGB)
Contrast Ratio 5,000:1
Power Supply 100-240 V AC, 50/60 Hz
Power Consumption (Max) 750 W/m²
Power Consumption (Typical) 250 W/m²
Weight Approximately 54 kg/m²

Wireless Features
Wireless Connectivity Optional (via external controller)

Compliance & Origin
Country of Origin Mexico
TAA Compliant Yes
Certifications FCC, UL, EMC Class A
RoHS Compliance Yes

Advanced Security Features
Access Authentication User-based access control (via software)
Network Security Firewall, HTTPS, SNMPv3 (via controller platform)
Remote Device Lockout Yes (via MagicINFO or third-party CMS)
Content Encryption AES 256-bit (via managed software)

Interfaces
Video Input HDMI, DVI, DisplayPort (varies by controller)
Control Interface Ethernet (RJ-45)
Service Interface USB
Data Transmission Fiber Optic / Ethernet-based Controller
Data Rate Support Up to 1 Gbps over Ethernet

Physical & Environmental
Cabinet Dimensions (W x H x D) 960 mm x 1,440 mm x 150 mm (typical)
Ingress Protection Rating IP65 (Front), IP54 (Rear)
Operating Temperature Range -30°C to 50°C
Storage Temperature Range -40°C to 60°C
Operating Humidity 10% – 90% RH (non-condensing)
Cooling Method Fan-Cooled, Ventilated Enclosure
Display Lifetime 100,000 hours (typical)

Cloud Management & Licensing
Remote Management Supported via Samsung MagicINFO or compatible CMS
Software Compatibility MagicINFO, Smart LED Signage Software
Cloud Management Platform MagicINFO (optional license)
Included Licensing None – license sold separately
