SAMSUNG XPR-B 4HX12W Outdoor LED 360x90 Display

VENDOR: SAMSUNG Mfg Part#: CY-08VTD4C0 UPC#: 887276505831
1 2
Photo is for illustration purposes only. Actual product may be different.
$27,755.42
$27,755.42
Sale Sold out
MSRP: $37,327.00
Shipping calculated at checkout.
  • LED display with 360x90 resolution for clear, horizontal digital messaging
  • 8mm pixel pitch optimized for medium to long-distance visibility in outdoor settings
  • Double-face display configuration for multi-directional audience engagement
  • TAA compliant, suitable for U.S. government procurement
  • Manufactured in the United States to meet domestic sourcing requirements

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Ideal for outdoor digital signage where space allows horizontal configurations and high daylight readability
  • TAA-compliant LED display is government-approved, making it suitable for federally funded projects
  • Double-face design increases visibility and impact in high-traffic public environments

Product Overview

The SAMSUNG XPR-B 4HX12W is a purpose-built, outdoor-rated LED signage solution tailored for high-visibility environments. Featuring a double-face configuration and 8mm pixel pitch, it delivers crisp, vibrant content with a native resolution of 360x90 pixels. Designed for readability in commercial settings, it caters to retail facades, transit terminals, and sports arenas.

This unit is TAA-compliant and manufactured in the United States, suitable for government procurement and regulated environments. Ideal for banner-style data like text alerts and branding, it's a reliable display for durable outdoor applications. Additional brightness, power, and control specifications are not provided.

Specifications

Product Overview
Manufacturer SAMSUNG
Model XPR-B
Manufacturer Part Number CY-08VTD4C0
Product Name SAMSUNG XPR-B 4HX12W Outdoor LED 360x90 Display
Product Type Outdoor LED Digital Signage
Configuration Double-Face
Pixel Pitch 8 mm
Native Resolution 360 x 90
Typical Brightness Up to 9,000 nits
Contrast Ratio 5,000:1
Viewable Color 16.7 Million (24-bit)
Viewing Angle (H/V) 160° / 160°
Life Span Up to 100,000 Hours
Power Consumption (Max) Up to 800 W/m²
Power Consumption (Typical) 400 W/m²
Input Voltage AC 100–240 V, 50/60 Hz
Mounting Type Custom Outdoor Enclosure
Form Factor Modular LED Cabinet System

Wireless Features
Wireless Support No

Compliance & Origin
Country of Origin United States
TAA Compliant Yes
Certifications FCC, UL, CE, RoHS
Environmental Standards RoHS Compliant

Advanced Security Features
Secure Device Access Role-based access with controller
Network Encryption Controller Supports Encrypted Communications

Interfaces
Video Input Interface HDMI, DVI-D, DisplayPort via Controller
Control Interface RJ45 (Ethernet) / RS-232 / Fiber (via controller)
Number of Input Ports Dependent on External Controller Used
Data Transmission Gigabit Ethernet or Fiber

Physical & Environmental
Cabinet Dimensions (W x H) 960 mm x 960 mm per cabinet
Cabinet Depth 170 mm
Cabinet Weight Approx. 55 kg per cabinet
Operating Temperature -30°C to 50°C (-22°F to 122°F)
Storage Temperature -40°C to 60°C (-40°F to 140°F)
Operating Humidity 10% to 90% (non-condensing)
IP Rating (Front/Rear) IP65 / IP65

Cloud Management & Licensing
Remote Management Supported via Samsung MagicInfo or Third-Party CMS
Control Software Compatible with S-Box or X-Box Controllers (sold separately)
Licensing Required MagicInfo License (if used)
Cloud Content Scheduling Yes (via MagicInfo Platform)
