SAMSUNG XPR-B 8mm Outdoor LED Display, Single Face, 3Hx9W

VENDOR: SAMSUNG Mfg Part#: LHX08VTB390 UPC#: 887276577753
1 2
Photo is for illustration purposes only. Actual product may be different.
$11,501.95
$11,501.95
Sale Sold out
MSRP: $15,376.38
Shipping calculated at checkout.
  • 8mm pixel pitch for outdoor LED display clarity
  • 270x90 resolution in 3Hx9W single face format
  • TAA compliant, eligible for government use
  • Manufactured in Mexico for regional compliance
  • Classified under Digital Signage Displays >45 inch
  • LED technology optimized for high-output visibility

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Designed for outdoor applications for maximum visibility in varied lighting conditions
  • TAA compliance ensures eligibility for public sector and federally regulated projects
  • Produced by Samsung, a recognized leader in display technology innovation

Product Overview

The SAMSUNG XPR-B 8mm Outdoor LED Single Face is a purpose-built digital signage solution ideal for outdoor visibility. Featuring a 270x90 resolution with a 3Hx9W single-face layout, it is engineered for drive-thru, roadside, or transit system displays. The 8mm pixel pitch offers impactful clarity, while TAA compliance and a Mexican origin make it suitable for public and government deployments. Designed for high brightness performance, this Samsung display is part of the brand's large-format professional range.

Specifications

Product Overview
Product Type Outdoor LED Digital Signage Display
Model Number LHX08VTB390
Series XPR-B Series
Display Configuration Single Face, 3Hx9W
Pixel Pitch 8 mm
Resolution 270 x 90 pixels
Brightness 9,000 nits (cd/m²)
Contrast Ratio 5,000:1
Viewing Angle (Horizontal/Vertical) 160° / 160°
Panel Technology Direct View LED
Number of Faces Single
Color Capability 16-bit color depth per color, 281 trillion colors
Lifetime (Half Brightness) 100,000 hours
Power Consumption (Max) 682 W/m²
Power Consumption (Typical) 227 W/m²
Power Supply 100-240V AC, 50/60Hz
Mounting Type Custom Frame or Pole Mounting (structure not included)

Wireless Features
Wireless Capability

Compliance & Origin
Country of Origin Mexico
TAA Compliance Yes
Certifications FCC, ETL, UL 60950-1, RoHS

Advanced Security Features
Secure Access Password-protected network access
Data Encryption AES-128 (via controller)

Interfaces
Input Interface RJ45 Ethernet
Control Interface Samsung XPS 4 Controller (sold separately)
Data Transfer Protocol Gigabit Ethernet

Physical & Environmental
Enclosure Type Weatherproof, Outdoor Rated
Cabinet Dimensions (Single Cabinet) 960 mm x 960 mm (W x H)
Display Dimensions (Est. 3Hx9W) 2.88 m x 0.96 m (W x H)
Cabinet Weight 34.2 kg per cabinet
Ingress Protection Rating IP66 (Front and Rear)
Operating Temperature -30°C to 50°C
Storage Temperature -40°C to 60°C
Operating Humidity 10% to 90% RH, non-condensing
Cooling Method Active cooling with rear ventilation

Cloud Management & Licensing
Display Management Platform Samsung XPS Platform (Optional)
Controller Compatibility Samsung XPS 4 Display Controller
Remote Monitoring Supported via Ethernet connection
Software Licensing Licenses required for XPS Software features
