| Product Type | Outdoor LED Display |
| Model Number | LHX08VTB380 |
| Pixel Pitch | 8 mm |
| Display Orientation | Single Face |
| LED Configuration | 3hx8w layout |
| Resolution | 240x90 |
| Brightness (Typical) | 7500 nits |
| Contrast Ratio | 5000:1 |
| Viewing Angle (H/V) | 160°/160° |
| Power Consumption (Max) | 850 W/m² |
| Power Consumption (Avg) | 340 W/m² |
| Power Supply | 100-240V AC, 50/60Hz |
| Cabinet Material | Aluminum |
| Cabinet Weight | 28.5 kg |
| Cabinet Type | Die-cast aluminum |
SAMSUNG XPR-B 8mm Outdoor LED Single Face Display
Photo is for illustration purposes only. Actual product may be different.
Regular price
$10,525.76
Regular price
Sale price
$10,525.76
Unit price
per
MSRP: $14,079.91
Shipping calculated at checkout.
Couldn't load pickup availability
- Outdoor LED display design with 8mm pixel pitch
- 240x90 pixel resolution in a 3hx8w configuration
- TAA compliant for government and regulated industry use
- Manufactured in Mexico, supporting NAFTA/USMCA trade standards
- Classified as Digital Signage Display >45 inch
Shipping & Returns
Shipping & Returns
All our products can be shipped anywhere in the Continental United States.
Key Benefits
Eye-Insights™ by Eye-In Technologies
AI-Powered Summaries from Online Customer Reviews
AI-Powered Summaries from Online Customer Reviews
Eye-Insights™ are generated by proprietary AI that analyzes real online customer reviews to highlight top pros and key product features. While we aim for accuracy, insights are provided “as-is” and individual results may vary.
- Built specifically for outdoor use with wide-format LED that maximizes visibility in variable lighting conditions
- TAA compliance ensures eligibility for government contracts and public sector deployment
- Large display layout supports scalable solutions in advertising, transportation, or event applications
Product Overview
The SAMSUNG XPR-B 8mm Outdoor LED Single Face display (model LHX08VTB380) delivers clear, vibrant visuals in high-traffic outdoor environments. Engineered for commercial and industrial signage, this single-faced LED panel features an 8mm pixel pitch and 240x90 resolution, structured in a 3hx8w layout. Manufactured in Mexico and fully TAA compliant, it's well-suited for public sector and commercial installations. With its classification in digital signage applications over 45 inches, it's ideal for large-scale deployments where visibility and reliability matter.
Specifications
Product Overview
Wireless Features
| Wireless Control Support | Optional via cloud controller |
Compliance & Origin
| Country of Origin | Mexico |
| TAA Compliant | Yes |
| Certifications | ETL, FCC, CE, EMC Class A |
| EMC Compliance | FCC Part 15, Class A |
| RoHS Compliant | Yes |
Advanced Security Features
| Access Control | User authentication via MagicINFO |
| Device Encryption | AES-128 content encryption (via MagicINFO) |
| Secure Communication Protocols | HTTPS, SNMP v3 |
Interfaces
| Input Signal | HDMI, DVI, DisplayPort (via controller) |
| Control Interface | RJ45 (Ethernet), USB (maintenance) |
| Data Input | Samsung S-Box (Remote Controller) |
Physical & Environmental
| Cabinet Dimensions (W x H x D) | 960 x 320 x 105 mm |
| IP Rating (Front) | IP65 |
| IP Rating (Rear) | IP65 |
| Operating Temperature Range | -30°C to +50°C |
| Storage Temperature Range | -40°C to +60°C |
| Operating Humidity | 10% to 90% (non-condensing) |
| Storage Humidity | 10% to 95% (non-condensing) |
| Environment | Outdoor |
| Cooling | Forced air cooling (internal fans) |
Cloud Management & Licensing
| Remote Management | Samsung MagicINFO supported |
| Cloud Software Compatibility | Yes, via MagicINFO Cloud |
| Licensing Requirements | MagicINFO license required (sold separately) |
| Monitoring Capabilities | Real-time diagnostics, content scheduling |
