SonicWall SonicWave 432O Wireless AP with Secure Wireless Mgmt 3YR (No PoE)

VENDOR: SONICWALL Mfg Part#: 01-SSC-2542
1 3
Photo is for illustration purposes only. Actual product may be different.
$1,696.73
$1,696.73
Sale Sold out
MSRP: $1,921.00
Shipping calculated at checkout.
  • Supports 802.11ac Wave 2, 802.11n, 802.11a/b/g/e/i/r/k/v/w standards
  • Dual-radio operation with 4x4 MU-MIMO for high user capacity
  • Operates on the 5.8 GHz frequency band with N-Type antenna connectors
  • Outdoor-ready form factor with compact design (9.5 x 9.3 x 2.4 cm)
  • Includes 3 years of secure wireless network management and support
  • TAA compliant and consumes a maximum of 21.2 Watts

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Integrated 3-year secure wireless management and support reduces IT overhead and enhances network reliability
  • Dual-radio 4x4 MU-MIMO design ensures consistent, high-throughput performance even in user-dense environments
  • Outdoor-rated build with flexible antenna connectivity enables reliable deployment in challenging conditions

Product Overview

The SonicWall SonicWave 432O wireless access point is optimized for modern enterprise and industrial wireless networking. This rugged, outdoor-certified unit supports multiple wireless standards including 802.11ac Wave 2 and operates in the 5.8 GHz band with 4x4 MU-MIMO for multi-user performance. It features N-Type antenna connectors for flexible deployments.

It includes 3 years of Essential Secure Wireless Network Management and Support for centralized control and reliability. TAA-compliant and highly efficient with a 21.2W power draw, it supports up to 8 access points per device. With compact dimensions and robust construction, it’s ideal for efficient and secure outdoor wireless expansion.

Specifications

Product Overview
Product Type Wireless Access Point
Model SonicWave 432O
Form Factor Outdoor, Wall/Pole Mountable
Environment Outdoor
Radio Count Dual
MIMO Type 4x4 MU-MIMO
Max Access Points Up to 8 per access point
Max Power Consumption 21.2 Watt
Power Input Type PoE+ (IEEE 802.3at), External Power Adapter not included
Mounting Options Pole, Wall
Weight 1.63 lbs (0.74 kg)

Wireless Features
Wireless Standards 802.11ac Wave 2, 802.11ac, 802.11n, 802.11g, 802.11b, 802.11a
Security Protocols WPA2, WPA3, 802.1X authentication
Wi-Fi Frequency Bands 2.4 GHz and 5 GHz
Wireless Transmission Speed Up to 1.733 Gbps (5 GHz), 800 Mbps (2.4 GHz)
Beamforming Yes, Transmit Beamforming (TxBF)
Band Steering Supported
Client Isolation Supported

Compliance & Origin
Country of Origin United States
TAA Compliance Yes
Certifications FCC Class B, ICES Class B, CE, UL, cUL, CB, VCCI
Environmental Standards RoHS, WEEE

Advanced Security Features
Wireless Intrusion Detection System (WIDS) Yes
Wireless Intrusion Prevention (WIPS) Yes
Rogue AP Detection & Prevention Supported
Content Filtering Support Yes, via SonicWall Security Services
Malware Detection Integrated with SonicWall Capture Security Center (when used with SonicWall Firewall)

Interfaces
Data Link Protocol Ethernet
Data Link Protocol Wi-Fi
Wired Interface 1 x 1G RJ45 Ethernet (PoE+)
Antenna Connectors N-Type
Antenna Type External Detachable Antennas (Not Included)
Number of Antennas Supported 4

Physical & Environmental
Height 2.4 cm
Width 9.5 cm
Depth 9.3 cm
Chassis Material IP67-Certified Rugged Enclosure
Ingress Protection Rating IP67
Operating Temperature -40°C to 65°C (-40°F to 149°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Operating Humidity 5% to 95% non-condensing

Cloud Management & Licensing
Management Interface SonicWall Wireless Network Manager (Cloud-Based)
Included Management License 3-Year Essential Secure Wireless Network Management and Support
Cloud Features Zero-Touch Deployment, Centralized Monitoring, Analytics, Configuration Management
