STARTECH M2E4SFF8643 U.2 to M.2 NVMe SSD Adapter, 2.5in Support

VENDOR: STARTECH Mfg Part#: M2E4SFF8643 UPC#: 065030872607
1 5
Photo is for illustration purposes only. Actual product may be different.
$18.05
$18.05
Sale Sold out
MSRP: $22.99
Shipping calculated at checkout.
  • Supports 2.5-inch U.2 PCIe SSDs (NVMe and AHCI)
  • Connects to M.2 PCIe x4 host interface
  • Compact size: 2.5 x 0.8 x 0.6 inches
  • Native OS support—no drivers required
  • TAA compliant for government procurement
  • Includes 2-year manufacturer warranty

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and return policy

View full details

Key Benefits

Eye-Insights
  • Boosts desktop/server performance by enabling high-speed U.2 PCIe SSDs via M.2 interface.
  • Ensures easy integration with native OS support—no need for additional drivers.
  • TAA compliance and 2-year warranty make it ideal for secure and reliable enterprise deployments.

Product Overview

Add U.2 PCIe NVMe SSD performance to your desktop computer or server by connecting a U.2 SSD to an M.2 PCIe x4 host interface - U.2 to M.2 Adapter for 2.5IN U.2 NVMe SSD - Native OS support - U.2 SSD Adapter - U.2 Drive Adapter - M2 PCIe Adapter

Specifications

Product Overview
Product Type Drive Converters
Form Factor Adapter bracket
Power Requirements Draws power from M.2 slot
Color Red
Weight 23 g
For Use With U.2 PCIe SSD (NVMe and AHCI)
Features Boost system performance by adding an enterprise-class U.2 PCIe NVMe SSD to your PC or server;
Service & Support Type 2 Years Warranty

Physical & Environmental
Width 0.8 Inch
Height 0.6 Inch
Depth 2.5 Inch
Product Length 64 mm
Product Width 20 mm
Product Height 15 mm
Operating Temperature 0°C to 50°C (32°F to 122°F)
Storage Temperature -25°C to 70°C (-13°F to 158°F)
Humidity 5% to 95% RH
Enclosure Type Metal

Cloud Management & Licensing
Software/Driver Required No (Native OS support)
OS Compatibility Windows, macOS, Linux – no drivers required

Interfaces
Host Interface M.2 PCIe x4 (M-Key, NVMe)
Drive Interface U.2 (SFF-8639)
Supported Drive Type 2.5" U.2 NVMe SSD (7mm height)
Connector Type SFF-8643 (Mini-SAS HD)
Drive Form Factor Supported 2.5in U.2
Bus Type PCI Express NVMe
Interface Bandwidth PCIe Gen 3.0 x4, up to 32Gbps

Compliance & Origin
TAA Compliance Yes
Country of Origin Taiwan
RoHS Compliance Yes
CE Certified Yes
FCC Compliance Yes
REACH Compliance Yes
WEEE Compliant Yes

Advanced Security Features
Encryption Support Depends on SSD used
Secure Boot Compatibility Yes, if host system supports
