TRENDnet TI-MGBS20 Hardened Mini-GBIC SFP Module, 1.25 Gbps, 20KM

VENDOR: TRENDNET Mfg Part#: TI-MGBS20 UPC#: 710931162875
1 5
Photo is for illustration purposes only. Actual product may be different.
$44.85
$44.85
Sale Sold out
MSRP: $45.99
Shipping calculated at checkout.
  • SFP form factor with LC duplex interface for compact, high-density installations
  • Supports single-mode fiber connections up to 20 km at 1310nm wavelength
  • Compliant with IEEE 802.3 and 802.3z Gigabit Ethernet standards
  • 1.25 Gbps data transfer rate over wired optical connection
  • TAA compliant and manufactured in Taiwan for regulatory suitability
  • Includes lifetime warranty for extended product support

Shipping & Returns

All our products can be shipped anywhere in the Continental United States.

View our shipping and returns policy

View full details

Key Benefits

Eye-Insights
  • Ideal for long-distance deployments with 20 Km maximum transfer range over single-mode fiber
  • Lifetime warranty ensures long-term reliability and reduces total ownership cost
  • Tested and certified to IEEE 802.3z standards, guaranteeing high network compatibility

Product Overview

The TRENDnet TI-MGBS20 is a hardened Mini-GBIC single-mode LC module designed for high-performance and long-distance networking applications. Featuring a standard SFP form factor, this transceiver supports 1.25 Gbps data transfer rates over a maximum distance of 20 kilometers, making it suitable for large-scale commercial or industrial Ethernet deployments. Engineered to comply with IEEE 802.3 and 802.3z standards, the TI-MGBS20 ensures optimal interoperability with Gigabit Ethernet networks.

Built for rugged environments, this module delivers a reliable wired connection with an LC duplex interface and a wavelength of 1310nm for efficient optical transmission. Its compact design, measuring just 2.2 by 0.5 inches, allows for easy integration into systems with limited cabinetry space. TAA compliance and a country of origin in Taiwan indicate a commitment to high manufacturing standards, while its lifetime warranty reflects long-term durability and low total cost of ownership for enterprise networks.

Specifications

Product Overview
Device Type Transceiver
Form Factor SFP
Type Hardened Mini-GBIC Single-Mode LC Module
Data Transfer Rate 1.25 Gbps
Data Link Protocol Gigabit Ethernet
Connectivity Technology Wired
Max Transfer Distance 20 Km
Wavelength 1310nm
Power Consumption Less than 1W
Power Supply 3.3V DC

Physical & Environmental
Width 2.2 inches
Depth 0.5 inches
Height 0.5 inches
Operating Temperature -40°C to 85°C (-40°F to 185°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Operating Humidity 5% to 95% RH (non-condensing)
Enclosure Type Metal
MTBF 1,290,774 hours

Cloud Management & Licensing
Management Interface Not applicable
License Included Not required

Service & Warranty
Service & Support Type Lifetime Warranty

Interfaces
Connector Type LC Duplex
Interface Type 1000Base-LX
Port Type Fiber optic
Fiber Type Single-mode
Hot Swappable Yes

Compliance & Origin
Country of Origin Taiwan
TAA Compliant Yes
Certifications CE, FCC
Environmental Compliance RoHS
Compliance Standards IEEE 802.3z, IEEE 802.3

Advanced Security Features
Security Features Not applicable
